Input Files and Code for: Machine learning can accurately assign geologic basin to produced water samples using major geochemical parameters

July 20, 2021

As more hydrocarbon production from hydraulic fracturing and other methods produce large volumes of water, innovative methods must be explored for treatment and reuse of these waters. However, understanding the general water chemistry of these fluids is essential to providing the best treatment options optimized for each producing area. Machine learning algorithms can often be applied to datasets to solve complex problems. In this study, we used the U.S. Geological Survey�s National Produced Waters Geochemical Database (USGS PWGD) in an exploratory exercise to determine if systematic variations exist between produced waters and geologic environment that could be used to accurately classify a water sample to a given geologic province. Two datasets were used, one with fewer attributes (n = 7) but more samples (n = 58,541) named PWGD7, and another with more attributes (n = 9) but fewer samples (n = 33,271) named PWGD9. The attributes of interest were specific gravity, pH, HCO3, Na, Mg, Ca, Cl, SO4, and total dissolved solids. The two datasets, PWGD7 and PWGD9, contained samples from 20 and 19 geologic provinces, respectively. Outliers across all attributes for each province were removed at a 99% confidence interval. Both datasets were divided into a training and test set using an 80/20 split and a 90/10 split, respectively. Random forest, Na�ve Bayes, and k-Nearest Neighbors algorithms were applied to the two different training datasets and used to predict on three different testing datasets. Overall model accuracies across the two datasets and three applied models ranged from 23.5% to 73.5%. A random forest algorithm (split rule = extratrees, mtry = 5) performed best on both datasets, producing an accuracy of 67.1% for a training set based on the PWGD7 dataset, and 73.5% for a training set based on the PWGD9 dataset. Overall, the three algorithms predicted more accurately on the PWGD7 dataset than PWGD9 dataset, suggesting that either a larger sample size and/or fewer attributes lead to a more successful predicting algorithm. Individual balanced accuracies for each producing province ranged from 50.6% (Anadarko) to 100% (Raton) for PWGD7, and from 44.5% (Gulf Coast) to 99.8% (Sedgwick) for PWGD9. Results from testing the model on recently published data outside of the USGS PWGD suggests that some provinces may be lacking information about their true geochemical diversity while others included in this dataset are well described. Expanding on this effort could lead to predictive tools that provide ranges of contaminants or other chemicals of concern within each province to design future treatment facilities to reclaim wastewater. We anticipate that this classification model will be improved over time as more diverse data are added to the USGS PWGD.

Publication Year 2021
Title Input Files and Code for: Machine learning can accurately assign geologic basin to produced water samples using major geochemical parameters
DOI 10.5066/P95G2SZC
Authors Mary R. Croke, Jenna L Shelton, Aaron M Jubb, Samuel W Saxe, Emil D Attanasi, Philip A Freeman, Madalyn S Blondes
Product Type Data Release
Record Source USGS Digital Object Identifier Catalog
USGS Organization Geology, Energy & Minerals Science Center
