Multibeam bathymetry and sediment depth data at select locations on the Des Plaines River near Joliet, Illinois, February 1314, 2017
September 22, 2017
These data are high-resolution bathymetry (river bottom elevation) in XYZ format and measurements of sediment depth in CSV format, generated from the February 1314, 2017, topographic and hydrographic survey of the Des Plaines River near Brandon Road Lock and Dam at Joliet, Illinois. Hydrographic data were collected in three separate areas (approach channel, mooring area, and upstream pool) using a multibeam echo-sounder (MBES) with integrated inertial navigation solution (INS) mounted on a marine survey vessel. Sediment depth data were collected in the approach channel using navigational software and probing equipment mounted on a marine survey vessel.
Citation Information
| Publication Year | 2017 |
|---|---|
| Title | Multibeam bathymetry and sediment depth data at select locations on the Des Plaines River near Joliet, Illinois, February 1314, 2017 |
| DOI | 10.5066/F7K935SH |
| Authors | Zachary W. Martin, Justin A. Boldt |
| Product Type | Data Release |
| Record Source | USGS Digital Object Identifier Catalog |
| USGS Organization | Ohio-Kentucky-Indiana Water Science Center |
Related Content
Flow hydraulics and mixing characteristics in and downstream from Brandon Road Lock, Joliet, Illinois
The Brandon Road Lock and Dam on the Des Plaines River near Joliet, Illinois, has been identified for potential implementation of aquatic nuisance species (ANS) control measures. To provide additional information concerning the flow hydraulics and mixing characteristics of the lock and downstream approach channel, the U.S. Geological Survey performed a detailed study of the site between December 2
Authors
Frank L. Engel, P. Ryan Jackson, Elizabeth A. Murphy
