Geologic map of the Bonners Ferry 30' x 60' quadrangle, Idaho and Montana

January 1, 2003

This data set maps and describes the geology of the Bonners Ferry 30' x 60' quadrangle, Idaho and Montana. The bedrock geology of the Bonners Ferry quadrangle consists of sedimentary, metamorphic, and granitic rocks ranging in age from Middle Proterozoic to Eocene. Bedrock units include rocks of (1) the Middle Proterozoic Belt Supergroup (2) the Middle Proterozoic Deer Trail Group, (3) the Late Proterozoic Windermere Group, (4) miogeoclinal or shelf facies lower Paleozoic rocks, and (5) Mesozoic and Tertiary granitic rocks.
The Belt Supergroup, a thick sequence of argillite, siltite, quartzite, and impure carbonate rocks up to 9,000 m thick, occurs in two non-contiguous sequences in the quadrangle: (1) the Clark Fork-Eastport Sequence east of the Purcell trench and (2) the Newport Sequence in the hanging wall of the Newport Fault. Only the two lowest Belt formations of the Newport Sequence are found in the Bonners Ferry quadrangle, but these two units are part of a continuous section, which extends southwestward to the town of Newport.

Belt Supergroup rocks of the Clark Fork-Eastport Sequence are separated from those of the Newport Sequence by the Newport Fault, Priest River Complex, and Purcell Trench Fault. Some formations of the Belt Supergroup show differences in thickness and (or) lithofacies from one sequence to the other that are greater than those predicted from an empirical depositional model for the distances currently separating the sequences. These anomalous thickness and facies differences suggest that there has been a net contraction along structures separating the sequences despite Eocene extension associated with emplacement of the Priest River Complex. In addition to these two Belt sequences, probable Belt rocks are present in the Priest River Complex as high metamorphic grade crystalline schist and gneiss.

Northwest of the Newport Sequence of Belt Supergroup is the Deer Trail Group, a distinct Middle Proterozoic sequence of argillite, siltite, quartzite, and carbonate rocks lithostratigraphically similar to the Belt Supergroup, but separated from all Belt Supergroup rocks by the Jumpoff Joe Fault. Rocks of the Deer Trail Group are pervasively phyllitic and noticeably more deformed than rocks in the Belt Supergroup sequences. Lithostratigraphically the Deer Trail Group is equivalent to part of the upper part of the Belt Supergroup. Differences in lithostratigraphy and thickness between individual Deer Trail and Belt units and between the Deer Trail and Belt sequences as a whole indicate that they were probably much farther apart when they were deposited.

The Windermere Group is a lithologically varied sequence of volcanic rocks and coarse-grained, mostly immature, clastic sedimentary rocks up to 8,000 m thick. It is characterized by extreme differences in thickness and lithofacies over short distances caused by syndepositional faulting associated with initial stages of continental rifting in the Late Proterozoic. Strata of the Windermere Group unconformably overlie only the Deer Trail Group, and are nowhere found in depositional contact with Belt Supergroup rocks.

Paleozoic rocks in the Bonners Ferry quadrangle consist of a thin, fault-bounded remnant preserved within the Clark Fork-Eastport Belt Supergroup Sequence.

Mesozoic granitic rocks underlie at least 50 percent of the Bonners Ferry quadrangle. They fall into two petrogenetic suites, hornblende-biotite plutons and muscovite-biotite (two-mica) plutons, most of which are Cretaceous in age. Both suites are represented in the mid-crustal Priest River Complex and in the higher level plutons that flank the complex; by far the majority of the Priest River Complex are Cretaceous, two-mica bodies.

Tertiary rocks are restricted to a single small stock, numerous hypabyssal dikes that are too small to show at the scale of the map, and to cataclastic rocks related to the Newport Fault.

Quaternary deposits include unconsolidated to poorl

Publication Year 2003
Title Geologic map of the Bonners Ferry 30' x 60' quadrangle, Idaho and Montana
DOI 10.3133/mf2426
Authors Fred K. Miller, Russell F. Burmester
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Miscellaneous Field Studies Map
Series Number 2426
Index ID mf2426
Record Source USGS Publications Warehouse
