Seabed maps showing topography, ruggedness, backscatter intensity, sediment mobility, and the distribution of geologic substrates in quadrangle 5 of the Stellwagen Bank National Marine Sanctuary region offshore of Boston, Massachusetts

The U.S. Geological Survey, in cooperation with the National Marine Sanctuary Program of the National Oceanic and Atmospheric Administration, has conducted seabed mapping and related research in the Stellwagen Bank National Marine Sanctuary (SBNMS) region since 1993. The area being mapped using geophysical and geological data includes the SBNMS and the surrounding region, which totals approximately 3,700 square kilometers (km²) and is subdivided into 18 quadrangles. The seabed is a glaciated terrain that is topographically and texturally diverse. Quadrangle 5, the subject of this scientific investigations map, has an area of 211 km² and has water depths that range from 23 meters (m) on the Stellwagen Bank crest to 105 m in the Stellwagen Basin. Seven map types, each at a scale of 1:25,000, depict seabed topography, ruggedness, backscatter intensity, distribution of geologic substrates, sediment mobility, distribution of fine- and coarse-grained sand, and substrate mud content. These maps show the distribution of geologic substrates on the crest and western flank of the south-central part of Stellwagen Bank and in Stellwagen Basin to the west. Interpretations of multibeam sonar bathymetric and seabed backscatter imagery, photographs, video imagery, and grain-size analyses were used to create the geology-based maps. Data from 729 stations were analyzed, including 620 sediment samples. The geologic substrate maps of quadrangle 5 show the distribution of 20 substrates that represent a wide range of textures, such as mobile and rippled sand, immobile sand, sand that partially veneers gravel, boulder ridges, and mud. Mapped substrates are characterized by sediment grain-size composition, surface morphology, substrate layering, the mobility or immobility of substrate surfaces, and water depth range. This scientific investigations map portrays the major geological elements (substrates, topographic features, and processes) of environments in quadrangle 5. It is intended to provide a foundation for research into present and past sediment transport processes in a complex terrain, provide insights into the ecological requirements of invertebrate and vertebrate species that utilize the various substrates, and to support seabed management in the region.
