A novel drive-point multilevel system to investigate PFAS and other contaminants of global concern in the hyporheic zone of a wastewater effluent dominated stream

Contaminants found in treated wastewater discharged to streams, including pharmaceuticals and per- and polyfluoroalkyl substances (PFAS), are of global concern due to their deleterious effects on aquatic ecosystems and potential impacts to human health. Hyporheic zones have strong potential for contaminant attenuation. Assessing this potential requires collection of physical and biogeochemical data within the hyporheic zone. This study tested the applicability of a novel drive-point multilevel system (DP-MLS) for quantifying head profiles and characterizing contaminant concentrations in the hyporheic zone of a temperate region effluent dominated stream (EDS). DP-MLS, each with 4 ports, were installed in the stream bed at two sites, DS-1 and DS-2, 0.2 and 4.7 km downstream of the effluent outfall, respectively. Head profiles were measured and groundwater collected for analysis of pharmaceuticals and PFAS temporally over two years. The DP-MLS withstood rapid changes in stage, ice formation, and floating debris. Vertical hydraulic gradients (VHG) were generally upward but varied in magnitude indicating heterogeneity in hydraulic conductivity and variability in flow conditions. Upward VHG were also about 2X larger at DS-1 than at DS-2. Contaminant concentration profiles consistently showed penetration of pharmaceuticals and PFAS to 1 m below the bed at DS-2 while there was less penetration, lower groundwater concentrations, and more temporal variability in concentrations at DS-1. Integration of the physical and chemical data suggests weaker upwelling conditions at DS-2 are more easily reversed during periods of high stream stage, which could facilitate migration of wastewater contaminants into the bed. However, further studies incorporating other transport processes and reach scale dynamics are required to fully characterize these exchanges. Overall, this study demonstrates the efficacy of these novel DP-MLSs for characterization of the hyporheic zone and provides new insights into the occurrence, composition, and persistence of wastewater derived contaminants in the hyporheic zone of a well-studied EDS.
