An analysis of the factors that control fault zone architecture and the importance of fault orientation relative to regional stress

March 6, 2020

The moment magnitude 7.2 El Mayor−Cucapah (EMC) earthquake of 2010 in northern Baja California, Mexico produced a cascading rupture that propagated through a geometrically diverse network of intersecting faults. These faults have been exhumed from depths of 6−10 km since the late Miocene based on low-temperature thermochronology, synkinematic alteration, and deformational fabrics. Coseismic slip of 1−6 m of the EMC event was accommodated by fault zones that displayed the full spectrum of architectural styles, from simple narrow fault zones (<100 m in width) that have a single high-strain core, to complex wide fault zones (>100 m in width) that have multiple anastomosing high-strain cores. As fault zone complexity and width increase the full spectrum of observed widths (20−200 m), coseismic slip becomes more broadly distributed on a greater number of scarps that form wider arrays. Thus, the infinitesimal slip of the surface rupture of a single earthquake strongly replicates many of the fabric elements that were developed during the long-term history of slip on the faults at deeper levels of the seismogenic crust. We find that factors such as protolith, normal stress, and displacement, which control gouge production in laboratory experiments, also affect the architectural complexity of natural faults. Fault zones developed in phyllosilicate-rich metasedimentary gneiss are generally wider and more complex than those developed in quartzo-feldspathic granitoid rocks. We hypothesize that the overall weakness and low strength contrast of faults developed in phyllosilicate rich host rocks leads to strain hardening and formation of broad, multi-stranded fault zones. Fault orientation also strongly affects fault zone complexity, which we find to increase with decreasing fault dip. We attribute this to the higher resolved normal stresses on gently dipping faults assuming a uniform stress field compatible with this extensional tectonic setting. The conditions that permit slip on misoriented surfaces with high normal stress should also produce failure of more optimally oriented slip systems in the fault zone, promoting complex branching and development of multiple high-strain cores. Overall, we find that fault zone architecture need not be strongly affected by differences in the amount of cumulative slip and instead is more strongly controlled by protolith and relative normal stress.

Publication Year 2020
Title An analysis of the factors that control fault zone architecture and the importance of fault orientation relative to regional stress
DOI 10.1130/B35308.1
Authors John Fletcher, Orlando Teran, Tom Rockwell, Michael E. Oskin, Kenneth W. Hudnut, Ronald Spelz, Pierre Lacan, Mathew Dorsey, Giles Ostermijer, Thomas M. Mitchell, Sinan Akciz, Ana Paula Hernandez-Flores, Alejandro Hinojosa-Corona, Ivan Peña-Villa, David K. Lynch
Publication Type Article
Publication Subtype Journal Article
Series Title GSA Bulletin
Index ID 70209737
Record Source USGS Publications Warehouse
USGS Organization Earthquake Science Center
