Archive of digital boomer seismic reflection data collected during USGS field activity 02LCA02 in Lakes Ada, Crystal, Jennie, Mary, Rice, and Sylvan, Central Florida, July 2002

May 30, 2008

In July of 2002, the U.S. Geological Survey and St. Johns River Water Management District (SJRWMD) conducted geophysical surveys in Lakes Ada, Crystal, Jennie, Mary, Rice, and Sylvan, central Florida, as part of the USGS Lakes and Coastal Aquifers (LCA) study. This report serves as an archive of unprocessed digital boomer seismic reflection data, trackline maps, navigation files, Geographic Information System (GIS) files, and formal Federal Geographic Data Committee (FGDC) metadata. Filtered and gained (a relative increase in signal amplitude) digital images of the seismic profiles are also provided. Refer to the Acronyms page for expansions of acronyms and abbreviations used in this report.

The archived trace data are in standard Society of Exploration Geophysicists (SEG) SEG-Y format (Barry and others, 1975) and may be downloaded and processed with commercial or public domain software such as Seismic Unix (SU). Example SU processing scripts and USGS software for viewing the SEG-Y files (Zihlman, 1992) are also provided.

The USGS Florida Integrated Science Center (FISC) - St. Petersburg assigns a unique identifier to each cruise or field activity. For example, 02LCA02 tells us the data were collected in 2002 for the Lakes and Coastal Aquifers (LCA) study and the data were collected during the second field activity for that study in that calendar year. Refer to… for a detailed description of the method used to assign the field activity ID.

The boomer plate is an acoustic energy source that consists of capacitors charged to a high voltage and discharged through a transducer in the water. The transducer is towed on a sled floating on the water surface and when discharged emits a short acoustic pulse, or shot, which propagates through the water, sediment column, or rock beneath. The acoustic energy is reflected at density boundaries (such as the seafloor, sediment, or rock layers beneath the seafloor), detected by the receiver, and recorded by a PC-based seismic acquisition system. This process is repeated at timed intervals (for example, 0.5 s) and recorded for specific intervals of time (for example, 100 ms). In this way, a two-dimensional (2-D) vertical profile of the shallow geologic structure beneath the ship track is produced. Figure 1 displays the acquisition geometry. Refer to table 1 for a summary of acquisition parameters. Table 2 lists trackline statistics.

The unprocessed seismic data are stored in SEG-Y format (Barry and others, 1975). For a detailed description of the data format, refer to the SEG-Y Format page. See the How To Download SEG-Y Data page for download instructions. The printable profiles provided here are GIF images that were filtered and gained using Seismic Unix software. Refer to the Software page for details about the processing and examples of the processing scripts. The processed SEG-Y data were exported to Chesapeake Technology, Inc. (CTI) SonarWeb software to produce an interactive Web page of the profile, which allows the user to obtain a geographic location and depth from the profile for a curser position. This information is displayed in the status bar of the browser.

Publication Year 2008
Title Archive of digital boomer seismic reflection data collected during USGS field activity 02LCA02 in Lakes Ada, Crystal, Jennie, Mary, Rice, and Sylvan, Central Florida, July 2002
DOI 10.3133/ds348
Authors Arnell S. Harrison, Shawn V. Dadisman, Jeffrey B. Davis, Dana S. Wiese
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 348
Index ID ds348
Record Source USGS Publications Warehouse
USGS Organization Florida Integrated Science Center - St. Petersburg; St. Petersburg Coastal and Marine Science Center
