Comparison of longitudinal stream temperature profiles and significant thermal features from airborne thermal infrared and float surveys of the Skykomish, Snoqualmie, and Middle Fork Snoqualmie Rivers, King and Snohomish Counties, Washington, summer 2020

Summer water temperatures in the Skykomish, Snoqualmie, and Middle Fork Snoqualmie Rivers in western Washington have in recent decades exceeded the water temperature criteria for aquatic life uses set by the Washington Department of Ecology. This temperature increase is of particular concern because these rivers provide critical habitat for several salmonid populations, including Endangered Species Act-listed Chinook salmon (Onchorhynchus tshawytscha), steelhead trout (O. mykiss), and bull trout (Salvelinus confluentus), thus helping sustain Endangered Species Act-listed Southern Resident orcas (Orcinus orca). To inform salmonid restoration efforts within these rivers, this study used high-resolution thermal infrared (TIR) and three-band red, green, blue imagery acquired from repeated airborne surveys conducted in August 2020 and 2021 to (1) quantify longitudinal stream temperature profiles (LTPs) and (2) identify and characterize significant thermal features (STFs), including cold-water anomalies that could represent thermal refuges and serve as salmonid habitat. In addition, drag-probe water temperature surveys (“float surveys”) were performed on the Skykomish and Middle Fork Snoqualmie Rivers during August–September 2020 and on a segment of the Middle Fork Snoqualmie River in August 2021. These float surveys were intended to evaluate this thermal profiling method in comparison to airborne TIR surveys, by employing a novel method of processing float survey data to adjust for diurnal heating.

The Middle Fork Snoqualmie River warmed about 7 degrees Celsius (°C) from upstream to downstream in the 2020 airborne TIR survey and 9 °C in the 2021 airborne TIR survey, and the Snoqualmie River warmed about 4 °C in both surveys. The water temperature of the Skykomish River cooled in the 2020 and 2021 surveys, primarily because of cold inflow from the Sultan River. The overall shapes of airborne TIR LTPs of the same river were similar in the 2020 and 2021 surveys, with increasing and decreasing gradients in temperature tending to be nearly parallel over the same reaches and abrupt changes in temperature typically identified at the same locations. A total of 854 STFs were identified in the 2020 TIR imagery, and 732 STFs were identified in the 2021 TIR imagery. Interannual persistence was detected in 36.4 to 61.3 percent of lateral groundwater, side channel, and small tributary STFs, depending on the river surveyed, and in 14.8 to 28.7 percent of hyporheic and diffuse groundwater STFs. Hyporheic flow was commonly detected at the downstream end of a riffle, but not often detected directly downstream from large woody debris. Shade from riparian vegetation did not reduce water temperatures but rather maintained the water temperature recorded just upstream from the shaded section.

The adjusted average water temperature profiles from the float surveys were comparable to the LTPs derived from the airborne TIR surveys, with differences in temperature gradient primarily because the surveys were performed under different streamflow, radiation, and shading conditions. Though float surveys were found to be a valuable means of obtaining thermal profiles comparable to profiles obtained by airborne TIR surveys, one key advantage of airborne TIR surveys is that they may be used to precisely locate STFs over long distances, during a short survey duration, and in areas inaccessible to most watercraft.
