Database compilation for the geologic map of the San Francisco volcanic field, north-central Arizona

January 8, 2016

The main component of this publication is a geologic map database prepared using geographic information system (GIS) applications. The geodatabase of geologic points, lines, and polygons was produced as a compilation from five adjoining map sections originally published as printed maps in 1987 (see references in metadata). Four of the sections (U.S. Geological Survey Miscellaneous Field Studies Maps MF–1957, MF–1958, MF–1959, MF–1960) were created by scanning and geo-referencing stable base map material consisting of mylar positives. The final section (MF–1956) was compiled by hand tracing an enlargement of the available printed paper base map onto mylar using a #00 rapidograph pen, the mylar positive was then digitally scanned and geo-referenced. This method was chosen because the original basemap materials (mylar positives) for the MF–1956 section were unavailable at the time of this publication. Due to the condition of the available MF–1956 map section used as the base (which had previously been folded) the accuracy within the boundary of the MF–1956 section is presumed to be degraded in certain areas. The locations of the degraded areas and the degree of degradation within these areas is unclear. Final compilation of the database was completed using the ArcScan toolset, and the Editor toolset in ESRI ArcMap 10.1. Polygon topology was created from the lines and labels were added to the resultant geological polygons, lines, and points. Joseph A. Bard and David W. Ramsey updated and corrected the geodatabase, created the metadata and web presence, and provided the GIS-expertise to bring the geodatabase and metadata to completion. Included are links to files to view or print the original map sheets and the accompanying pamphlets.

The orignial geologic maps were prepared under the Geothermal Research Program of the U.S. Geological Survey as a basis for interpreting the history of magmatic activity in the volcanic field. The San Francisco field, which is largely Pleistocene in age, is in northern Arizona, just north of the broad transition zone between the Colorado Plateau and the Basin and Range province. It is one of several dominantly basaltic volcanic fields of the late Cenozoic age situated near the margin of the Colorado Plateau. The volcanic field contains rocks ranging in composition from basalt to rhyolite—the products of eruption through Precambrian basement rocks and approximately a kilometer of overlying, nearly horizontal, Paleozoic and Mesozoic sedimentary rocks. About 500 km3 of erupted rocks cover about 5,000 km2 of predominantly Permian and locally preserved Triassic sedimentary rocks that form the erosionally stripped surface of the Colorado Plateau in Northern Arizona.

Citation Information

Publication Year 2015
Title Database compilation for the geologic map of the San Francisco volcanic field, north-central Arizona
DOI 10.3133/ds961
Authors Joseph A. Bard, David W. Ramsey, Edward W. Wolfe, George E. Ulrich, Christopher G. Newhall, Richard B. Moore, Norman G. Bailey, Richard F. Holm
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 961
Index ID ds961
Record Source USGS Publications Warehouse
USGS Organization Volcano Science Center
