EAARL Coastal Topography-Cape Hatteras National Seashore, North Carolina, Post-Nor'Ida, 2009: Bare Earth

April 9, 2011

These remotely sensed, geographically referenced elevation measurements of lidar-derived bare-earth (BE) topography datasets were produced collaboratively by the U.S. Geological Survey (USGS), St. Petersburg Coastal and Marine Science Center, St. Petersburg, FL, and the National Park Service (NPS), Northeast Coastal and Barrier Network, Kingston, RI. This project provides highly detailed and accurate datasets of a portion of the National Park Service Southeast Coast Network's Cape Hatteras National Seashore in North Carolina, acquired post-Nor'Ida (November 2009 nor'easter) on November 27 and 29 and December 1, 2009. The datasets are made available for use as a management tool to research scientists and natural-resource managers. An innovative airborne lidar instrument originally developed at the NASA Wallops Flight Facility, and known as the Experimental Advanced Airborne Research Lidar (EAARL), was used during data acquisition. The EAARL system is a raster-scanning, waveform-resolving, green-wavelength (532-nanometer) lidar designed to map near-shore bathymetry, topography, and vegetation structure simultaneously. The EAARL sensor suite includes the raster-scanning, water-penetrating full-waveform adaptive lidar, a down-looking red-green-blue (RGB) digital camera, a high-resolution multispectral color-infrared (CIR) camera, two precision dual-frequency kinematic carrier-phase GPS receivers, and an integrated miniature digital inertial measurement unit, which provide for sub-meter georeferencing of each laser sample. The nominal EAARL platform is a twin-engine aircraft, but the instrument was deployed on a Pilatus PC-6. A single pilot, a lidar operator, and a data analyst constitute the crew for most survey operations. This sensor has the potential to make significant contributions in measuring sub-aerial and submarine coastal topography within cross-environmental surveys. Elevation measurements were collected over the survey area using the EAARL system, and the resulting data were then processed using the Airborne Lidar Processing System (ALPS), a custom-built processing system developed in a NASA-USGS collaboration. ALPS supports the exploration and processing of lidar data in an interactive or batch mode. Modules for presurvey flight-line definition, flight-path plotting, lidar raster and waveform investigation, and digital camera image playback have been developed. Processing algorithms have been developed to extract the range to the first and last significant return within each waveform. ALPS is used routinely to create maps that represent submerged or sub-aerial topography. Specialized filtering algorithms have been implemented to determine the 'bare earth' under vegetation from a point cloud of last return elevations.

Publication Year 2011
Title EAARL Coastal Topography-Cape Hatteras National Seashore, North Carolina, Post-Nor'Ida, 2009: Bare Earth
DOI 10.3133/ds578
Authors J.M. Bonisteel-Cormier, Amar Nayegandhi, Xan Fredericks, J. C. Brock, C. W. Wright, D.B. Nagle, Sara Stevens
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 578
Index ID ds578
Record Source USGS Publications Warehouse
USGS Organization St. Petersburg Coastal and Marine Science Center
