Entrainment, retention, and transport of freely swimming fish in junction gaps between commercial barges operating on the Illinois Waterway

September 9, 2016

Large Electric Dispersal Barriers were constructed in the Chicago Sanitary and Ship Canal (CSSC) to prevent the transfer of invasive fish species between the Mississippi River Basin and the Great Lakes Basin while simultaneously allowing the passage of commercial barge traffic. We investigated the potential for entrainment, retention, and transport of freely swimming fish within large gaps (> 50 m3) created at junction points between barges. Modified mark and capture trials were employed to assess fish entrainment, retention, and transport by barge tows. A multi-beam sonar system enabled estimation of fish abundance within barge junction gaps. Barges were also instrumented with acoustic Doppler velocity meters to map the velocity distribution in the water surrounding the barge and in the gap formed at the junction of two barges. Results indicate that the water inside the gap can move upstream with a barge tow at speeds near the barge tow travel speed. Water within 1 m to the side of the barge junction gaps was observed to move upstream with the barge tow. Observed transverse and vertical water velocities suggest pathways by which fish may potentially be entrained into barge junction gaps. Results of mark and capture trials provide direct evidence that small fish can become entrained by barges, retained within junction gaps, and transported over distances of at least 15.5 km. Fish entrained within the barge junction gap were retained in that space as the barge tow transited through locks and the Electric Dispersal Barriers, which would be expected to impede fish movement upstream.

Publication Year 2016
Title Entrainment, retention, and transport of freely swimming fish in junction gaps between commercial barges operating on the Illinois Waterway
DOI 10.1016/j.jglr.2016.05.005
Authors Jeremiah J. Davis, P. Ryan Jackson, Frank L. Engel, Jessica Z. LeRoy, Rebecca N. Neeley, Samuel T. Finney, Elizabeth A. Murphy
Publication Type Article
Publication Subtype Journal Article
Series Title Journal of Great Lakes Research
Index ID 70176364
Record Source USGS Publications Warehouse
USGS Organization Illinois Water Science Center
