Evaluation of geophysical logs and aquifer-isolation tests, Phase III, August 2002 to March 2004, Crossley Farm superfund site, Hereford township, Berks County, Pennsylvania

September 19, 2006

Between August 2002 and March 2004, geophysical logging was conducted in 23 boreholes at the Crossley Farm Superfund Site, Hereford Township, Berks County, Pa., to determine the water-producing zones, water-receiving zones, zones of vertical-borehole flow, and fracture orientation where applicable. The boreholes ranged in depth from 71 to 503 ft (feet) below land surface. The geophysical logging determined the placement of well screens and packers, which allow monitoring and sampling of water-bearing zones in the fractured bedrock so the horizontal and vertical distribution of contaminated ground water migrating from known sources could be determined. Geophysical logging included collection of caliper (22 boreholes), fluid-temperature (17 boreholes), single-pointresistance (17 boreholes), natural-gamma (17 boreholes), fluidflow (18 boreholes), and acoustic-televiewer (13 boreholes) logs. Caliper and acoustic-televiewer logs were used to locate fractures, joints, and weathered zones. Inflections on fluid-temperature and single-point-resistance logs indicated possible water-bearing zones, and flowmeter measurements verified these locations. Single-point-resistance, natural-gamma, and geologist logs provided information on stratigraphy; the geologist log also provided information on the location of possible water-producing zones.

Borehole geophysical logging and heatpulse flowmetering indicated active flow in 10 boreholes. Seven of the boreholes are in ground-water discharge areas and three boreholes are in ground-water recharge areas. Heatpulse flowmetering, in conjunction with the geologist logs, indicates lithologic contacts (changes in lithology from a gneiss dominated by quartz-plagioclase-feldspar mineralogy to a gneiss dominated by hornblende mineralogy) are typically fractured, permeable, and effective transmitters of water.

Single-well, aquifer-isolation (packer) tests were performed on two boreholes. Packers were set at depths ranging from 210 to 465 ft below land surface to isolate water-bearing zones at discrete intervals. Placement and inflation of the packers provided information on hydraulic heads, specific capacities, the hydraulic connection between intervals, and depth-specific water-quality samples.

Upon completion of borehole geophysical logging and interpretation of geophysical logs, geologist logs, drillers notes, and packer work, 13 boreholes were reconstructed such that water levels could be monitored and water samples could be collected from discrete shallow, intermediate, and deep waterbearing fractures in each borehole. Boreholes BE-1672, BE-1674, BE-1676, and BE-1677 remained open-hole for sampling purposes. Boreholes RI-2, RI-3, and RI-4 remained openhole for injection purposes. Boreholes P-1, P-2, and P-3 remained open and were converted to pumping wells.

Citation Information

Publication Year 2006
Title Evaluation of geophysical logs and aquifer-isolation tests, Phase III, August 2002 to March 2004, Crossley Farm superfund site, Hereford township, Berks County, Pennsylvania
DOI 10.3133/sir20065090
Authors Randall W. Conger, Dennis J. Low
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2006-5090
Index ID sir20065090
Record Source USGS Publications Warehouse
USGS Organization Pennsylvania Water Science Center
