Flood-inundation maps for the Blue River near Red Bridge Road, Kansas City, Missouri, 2019

May 28, 2021

Digital flood-inundation maps for a 4.6-mile reach of the Blue River near Red Bridge Road in Kansas City, Missouri, were created by the U.S. Geological Survey (USGS), in cooperation with the City of Kansas City, Missouri. The flood-inundation maps, which can be accessed through the USGS Flood Inundation Mapping Program website at, depict estimates of the areal extent and depth of flooding corresponding to selected water levels (stages) at the USGS streamgage 06893195, Blue River at Red Bridge Road, Kansas City, Mo. Near-real-time stages at this streamgage may be obtained from the USGS National Water Information System at or the Johnson County, Kansas, StormWatch Automated Local Elevation in Real Time Flood Warning System at

Flood profiles were computed for the Blue River reach by means of a one-dimensional model for simulating water-surface profiles with steady-state flow computations. The model was calibrated by using the current stage-streamflow relations at the upstream USGS streamgage 06893150, Blue River at Blue Ridge Boulevard Extension, Kansas City, Mo., and the downstream streamgage 06893500, Blue River at Kansas City, Mo.

The hydraulic model was then used to compute 37 water-surface profiles for flood stages at 1-foot (ft) intervals referenced to the streamgage datum and ranging from 11 ft, or near bankfull, to 47 ft at the reference streamgage 06893195. The upper stage for the map library exceeds the stage corresponding to the estimated 0.2-percent annual exceedance probability flood (500-year recurrence interval flood) in the model reach. The simulated water-surface profiles were then combined with a geographic information system digital elevation model with a maximum 10-centimeter vertical root mean square error and 4.0-ft horizontal resolution to delineate the area flooded at each water level.

The availability of these maps, along with real-time internet information regarding current stage from the USGS streamgage, will help guide emergency management personnel and residents in flood mitigation, preparedness and planning, flood-response activities such as evacuations and road closures, and any postflood recovery efforts.

Publication Year 2021
Title Flood-inundation maps for the Blue River near Red Bridge Road, Kansas City, Missouri, 2019
DOI 10.3133/sir20205057
Authors David C. Heimann, Jonathon D. Voss, Paul H. Rydlund
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2020-5057
Index ID sir20205057
Record Source USGS Publications Warehouse
USGS Organization Central Midwest Water Science Center
