Flood-inundation maps for Joachim Creek, De Soto, Missouri, 2018

August 15, 2019

Digital flood-inundation maps for a 6.7-mile reach of Joachim Creek, De Soto, Missouri, were created by the U.S. Geological Survey (USGS) in cooperation with the city of De Soto and Jefferson County, Missouri. The flood-inundation maps, which can be accessed through the USGS Flood Inundation Mapping Program website at, depict estimates of the areal extent and depth of flooding corresponding to selected water levels (stages) at the USGS streamgage Joachim Creek at De Soto, Missouri (station number 07019500). Near-real-time stages at this streamgage may be obtained on the internet from the USGS National Water Information System at or the National Weather Service Advanced Hydrologic Prediction Service at, which also forecasts flood hydrographs at this site (site DESM7).

Flood profiles were computed for the stream reach using a one-dimensional model for simulation of water-surface profiles with steady-state (gradually varied) or unsteady-state flow computation options. The model was calibrated by using the theoretical stage-discharge relation at the USGS streamgage Joachim Creek at De Soto, Missouri (station number 07019500), and documented high-water marks from the flood of April 18, 2013.

The hydraulic model was then used to compute 10 water surface profiles for flood stages at 1-foot (ft) intervals referenced to the streamgage datum. The profiles ranged from 8.0 ft, or near bankfull, to 17.0 ft, which exceeds the stage that corresponds to the estimated 0.2-percent annual exceedance probability flood (500-year recurrence interval flood). The simulated water-surface profiles were then combined with a geographic information system digital elevation model (derived from light detection and ranging data having a 0.60-ft vertical accuracy and 1.97-ft horizontal resolution) to delineate the area flooded at each water level.

The availability of these maps, along with internet information regarding current stage from the USGS streamgage and forecasted high-flow stages from the National Weather Service, will provide emergency management personnel and residents with information that is critical for flood-response activities such as evacuations and road closures and for post-flood recovery efforts.

Publication Year 2019
Title Flood-inundation maps for Joachim Creek, De Soto, Missouri, 2018
DOI 10.3133/sir20195068
Authors David C. Heimann, Jonathan D. Voss, Paul H. Rydlund
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2019-5068
Index ID sir20195068
Record Source USGS Publications Warehouse
USGS Organization Missouri Water Science Center; Central Midwest Water Science Center
