The growth of southern Laurentia has been attributed to the accretion of juvenile arc terranes during the successive 1.74-1.68 Ga Yavapai and 1.65-1.60 Ga Mazatzal orogenies. However, in light of the increasing importance of the ca. 1.49-1.40 Ga Mesoproterozoic Picuris orogeny, the tectonic setting in which the Mazatzal crustal province and its distinctive quartzite-rhyolite successions were generated needs additional examination. The Sandia-Manzano-Los Pinos uplift in central New Mexico is an ideal place to characterize the tectonic history of the Mazatzal crustal province. A comprehensive geochronologic and Hf-isotopic dataset for Proterozoic rocks of the Sandia-Manzano-Los Pinos uplift is presented. Plutonic and metavolcanic rocks in the Sandia-Manzano-Los Pinos uplift were emplaced in three pulses at 1668-1655 Ma, 1587 Ma, and 1459-1453 Ma. Hf-isotope data from the Paleoproterozoic plutonic rocks are juvenile, with both leucogranite and arc-related granodiorite yielding εHf(t) values ranging from +6 to +12, compared to the coeval depleted mantle value of +10 at ca. 1.65 Ga. Inherited zircon in Paleoproterozoic rocks suggest that crust older than 1.7 Ga was involved in their genesis. Hf-isotope data from Mesoproterozoic plutonic rocks in the Sandia-Manzano-Los Pinos uplift are consistent with derivation from 1.7-1.6 Ga lithosphere. Detrital zircon indicate that metasedimentary rocks of the lower Manzano Group were derived primarily from local sources that have U-Pb-Hf isotope compositions similar to the plutonic rocks which intrude and volcanic rocks that underlie the Manzano Group. The detrital zircon provenance of the Manzano Group broadens up-section from unimodal populations with age peaks at ca. 1.65 Ga to include 1.7-3.0 Ga detrital zircon derived from older Laurentian sources like the Yavapai and Mojave provinces. We offer a new model for the formation of the Mazatzal crustal province of New Mexico as a continental margin arc built on top of the previously assembled Yavapai province. The Manzano Group quartzite-rhyolite succession was formed by lithospheric extension above a north-dipping, southward retreating subduction zone. The Manzano Group was then subjected to ca. 1.65 Ga syn-magmatic tectonism and later intracratonic contractional tectonism, likely during the 1.46-1.40 Ga Picuris orogeny.
|Title||Geochronologic and Hf-isotope framework of Proterozoic rocks from central New Mexico, USA: Formation of the Mazatzal crustal province in an extended continental margin arc|
|Authors||Mark E. Holland, Tyler A. Grambling, Karl E. Karlstrom, James V. Jones, Kimberly N. Nagotko, Christopher G. Daniel|
|Publication Subtype||Journal Article|
|Series Title||Precambrian Research|
|Record Source||USGS Publications Warehouse|
|USGS Organization||Alaska Science Center Geology Minerals|
