Hydrogeologic conceptualization of the Arroyos subarea and Northeast Air Force Research Laboratory subarea of the Air Force Research Laboratory, Edwards Air Force Base, Antelope Valley, California, 2017–21

Research and testing within the Air Force Research Laboratory at Edwards Air Force Base in the southwestern Mojave Desert has been conducted since the 1950s. This testing requires large quantities of groundwater for cooling and operations involving hazardous constituents that have entered the groundwater. To better understand the potential movement of contaminants through the groundwater system, the U.S. Geological Survey entered into a cooperative agreement with the U.S. Air Force Civil Engineer Center with the purpose of (1) gaining a more detailed understanding of the hydraulic connection between the unconsolidated basin-fill sediment and the underlying weathered and crystalline bedrock and (2) investigating faults and their potential effect on groundwater flow. This study was specific to the Arroyos subarea and Northeast Air Force Research Laboratory subarea of the Air Force Research Laboratory. The refined hydrogeologic characterization was derived by evaluating surface geologic maps, a regional gravity model, new subsurface geophysical surveys, lithology data from boreholes, and groundwater-level data. Refinement of the hydrogeologic characterization of the study area involved developing a map of basin-fill sediment thickness, estimating the geometry and depth to bedrock, determining the presence of weathered bedrock material, and identifying the location of faults and subsurface structures. The thickness of basin-fill sediment was derived from a regional gravity model. Basin-fill sediment ranges from less than 20 feet (ft) thick to about 150 ft thick and increases substantially toward a deep structural basin in the northwestern part of the study area. The top of bedrock estimated from the new surface geophysical surveys is generally deeper than the top of bedrock from the regional gravity model. These differences in interpreted bedrock tops indicate that there may be a zone of weathered bedrock in the subsurface, overlying crystalline bedrock. Additional subsurface data evaluating the geometry and thickness of weathered bedrock are necessary for a comprehensive evaluation of weathered bedrock in the study area. Previously unmapped extensions of the Leuhman Fault, Spring Fault Zone, and Boron Gate Fault were identified in the new surface geophysical surveys. Evaluation of groundwater flow between bedrock and basin-fill sediment, and the effects of faults on groundwater flow, was done using groundwater-level data from 2020. The groundwater table was in crystalline bedrock throughout most of the Arroyos and Northeast Air Force Research Laboratory subareas, with a few exceptions where it was in basin-fill sediment and weathered bedrock. Basin-fill sediment, and likely weathered bedrock, was partially saturated in parts of the study area where basin-fill sediment was as thick as 150 ft. Weathered bedrock material may be present near the Spring Fault Zone, and if so, was likely saturated in 2020. The groundwater-level data near and within Spring Fault Zone indicate that the Spring Fault Zone acts as a vertical-along-strike conduit for, and as an across-strike impediment to, groundwater flow. In addition, steep groundwater-level gradients in the southeastern part of the study area indicate that a subsurface structure affecting groundwater flow could be related to the Leuhman Fault. Sufficient groundwater-level data were not available to conclusively determine if the Arroyos, Rich, and Boron Gate Faults, and their inferred extensions from the geophysical surveys, affect the movement or direction of groundwater flow.
