Hydrology of Area 1, eastern coal province, Pennsylvania [West Branch Susquehanna River, Sinnemahoning Creek, Upper Juniata River, Clearfield Creek]

January 1, 1983

Provisions of the Surface Mining Control and Reclamation Act of 1977 recognized a nationwide need for hydrologic information in mined and potentially mined areas. This report is designed to be useful to mine owners, operators, regulatory authorities, citizens groups, and others by presenting information on existing hydrologic conditions and by identifying additional sources of hydrologic information. General hydrologic information is presented in a brief text accompanied by a map, chart, graph, or other illustration for each of a series of water resources-related topics. The summation of the topical discussions provides a description of the hydrology of the area.

The Eastern Coal Province has been divided into 24 hydrologic study areas which are shown on the cover of this report. The divisions are based on hydrologic factors, location, and size. Hydrologic units (surface drainage basins) or parts of units are combined to form each study area.

Area 1 covers 7,400 square miles of the Eastern Coal Province in part or all of 18 counties in west-central Pennsylvania. The major streams in the area are the West Branch Susquehanna and Juniata Rivers. Area 1 counties produced more than 20,000,000 tons of coal during 1979. About 66,000 acres of disturbed coal land in Area 1 counties are in need of reclamation.

Streamflow data have been collected at 146 locations in the area, and water-quality data have been collected at 123 locations. Interpretations of water quality in this report are generally based on a series of four water-quality samples collected at each of 113 locations during the 1979-80 water years. Water-quality data collected at these sites included: specific conductance; dissolved solids; pH; acidity; alkalinty; total and dissolved iron; total and dissolved manganese; sulfate; and bed-material iron, manganese, coal, and organic carbon. Most sites had benthic invertebrate populations sampled and analyses of bed-material constituents. A smaller set of sites was sampled for common constituents and minor elements.

Streams in Clearfield and Cambria Counties, the two leading coal producers in the area, had median specific conductances and dissolved-solids concentrations three to five times greater than those from other area counties. Clearfield County streams had the lowest median stream pH in the area. Most streams sampled in the area had acidity in excess of alkalinity. Streams in the three major coal producing counties in the area had median total-iron concentrations two to three times higher than those for other area counties, and the same general pattern was found for total manganese. The median sulfate concentration of a county's streams showed a close positive correlation with the amount of coal mined in the county. Iron and coal concentrations in bed material were higher in coal-producing counties, but manganese concentrations in bed material were not higher. Twenty-eight streams did not have a benthic biological community as defined by the Office of Surface Mining. Three-fourths of the sites with no biological community had levels of pH, acidity, iron, manganese, and sulfate indicative of acid mine drainage.

Statistics on low flow, mean flow, peak flow, and flow-duration can be computed from gaging station records for gaged streams. The same statistics can be estimated for ungaged streams through the use of regression or graphical techniques. This information may be useful in preparing and evaluating mine-permit applications.

Aquifers in the area receive most recharge from precipitation on outcrop areas. Highest ground-water levels generally occur in spring, decline during the summer, and begin to rise again during the fall. Water levels in valleys generally show less fluctuation than on hills. Median well yields in the area range from 5 to 50 gallons per minute. Ground-water supplies are obtained from more than 40 formations. Ground-water quality is generally suitable for most uses.

Publication Year 1983
Title Hydrology of Area 1, eastern coal province, Pennsylvania [West Branch Susquehanna River, Sinnemahoning Creek, Upper Juniata River, Clearfield Creek]
DOI 10.3133/ofr83223
Authors William J. Herb, Deborah E. Brown, Lewis C. Shaw, Albert E. Becher
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 83-223
Index ID ofr83223
Record Source USGS Publications Warehouse
USGS Organization Pennsylvania Water Science Center
