Modified level II streambed-scour analysis for structure I-74-32-4946 crossing Sugar Creek in Montgomery County, Indiana

Level II scour evaluations follow a process in which hydrologic, hydraulic, and sedient-transport data are evaluated to calculate the depth of scour that may result when given discharge is routed through a bridge opening. The results of the modified Levell II analysis for structure I-74-32-4946 on Interstate 74 crossing Sugar Creek in Montgomery County, Indiana are presented. The site is near the town of Crawfordsville in the central part of Montgomery County. Scour depths were computed with the Water Surface PROfile model, version V050196, which incorporates the scour-calculation procedures outlined in Hydraulic Engineering Circular No. 18. Total scour depths at the piers were approximately 13.0 feet for the modeled discharge of 3,000  cubic feet per second and approximately 15.1 feet for the modeled discharge of 41,900 cubic feet per second.
