The purpose of drilling into the San Andreas fault zone is threefold. First, recovery of material from depth will permit determination of the composition and constitutive properties of both solid and fluid phases. Second, it will enable measurements of the physical state of the fault zone to be made (that is, the state of in-situ stress, pore pressure, and temperature). Finally, it will allow emplacement of instruments at depth in the fault zone as part of experiments related to earthquake prediction.
This report briefly describes the drilling history and preliminary analysis of fault zone materials from site Dry Lake Valley (DLV) No. 1 (Fig. 1). The site is located at Lat. 36028.09'N, Long. 12103.32'W. This site was chosen in an attempt to drill a 1 km deep well that would reach earthquake foci. Although the entire central section of the San Andreas fault is characterized by moderate seismicity and aseismic creep, Dry Lake Valley has particularly shallow earthquakes as well as a fairly high creep rate (18-20 mm/year, S. Schultz, pers. comm.). Fig. 2 is a longitudinal section along the San Andreas fault showing high precision locations of magnitude one or greater earthquakes that occurred in 1973-1975 (from W. Ellsworth, per. comm.). The depth accuracy of the earthquakes shown is about ± 0.5 km, and it is obvious from Figure 2 that Dry Lake Valley earthquakes are extremely shallow.
As shown in Figure 1 the general geology of the central section of the San Andreas fault consists of Tertiary to Jurassic sedimentary and volcanic rocks overlying Cretaceous age Gabilan granite of the Salinian Block on the west side of the fault and Cretaceous-Jurassic sedimentary assemblages of the Franciscan Complex to the east of the fault. Dibblee (1979) summarizes the geology along the central San Andreas fault. At the Dry Lake Valley site as much as 2 km of Pliocene-Miocene marine sediments (Etchegoin and Santa Margarita formation) overlie Franciscan rocks on the northeast side of the San Andreas fault. On the southwestern side of the fault, 1-2 km of Pliocene-Miocene valley sediments and granitic conglomerate overlies the Gabilan granite.
