Reconnaissance of potential alternate water supply sources for the City of Gary, West Virginia

Seven potential sources of water, consisting of free-flowing discharge from abandoned coal mines at six locations and one abandoned flooded underground coal mine air shaft, were sampled for chemical analysis to assess the quality of the groundwater emanating from the seven mine sources. The six free-flowing mine discharge sources were also assessed for discharge by current-meter measurements on two separate occasions. The U.S. Geological Survey assessed these seven sources to provide information to the City of Gary, West Virginia (W. Va.), and the City of Gary’s consulting engineer with groundwater-quality and flow data to allow them to assess the seven sites as potential alternate sources of water for the City of Gary to augment its existing supply.

For the six sites where discharge could be measured, discharge ranged from a minimum of 0.082 cubic feet per second (ft³/s) to a maximum of 3.685 ft³/s. Of the six sites measured, only two, Harmon Branch at Thorpe, W. Va. (USGS site 372201081303501) and the abandoned public-supply water wells near Havaco, W. Va. (USGS site 372358081344601), had discharge in excess of 1.00 ft³/s. Discharge from the abandoned public supply wells was 3.685 ft³/s on September 20, 2023, and 2.888 ft³/s on October 16, 2023, and discharge from Harmon Branch at Thorpe, W. Va., was 1.049 ft³/s on September 22, 2023, and 1.038 ft³/s on October 17, 2023. Discharge in the abandoned underground mine air shaft (USGS site 372224081340901) could not be assessed, but the air shaft drains an abandoned mine that likely contains water stored in approximately 1.7 square miles (mi²) of abandoned underground coal mines in the Pocahontas No. 3 coal seam, and possibly an additional 0.9 mi² of leakage from the overlying Pocahontas No. 4 coal seam. Discharge for the six sites measured for the study was measured during a period between September 20 and October 18, 2023, and corresponded to the 12th to the 15th percentile of flow-duration statistics for the Tug Fork downstream of Elkhorn Creek at Welch, W. Va. streamgage (USGS site 03212750).

Water-quality data for the seven sites sampled overall were acceptable with respect to drinking water standards. Of the 203 constituents analyzed, only a few failed to meet applicable U.S. Environmental Protection Agency (EPA) drinking water standards. Iron exceeded the 300 micrograms per liter (μg/L) secondary maximum contaminant level (SMCL) at only 1 of the 7 sites (14.3 percent) sampled. Iron concentrations ranged from a minimum of less than (<) 5.00 μg/L to a maximum of 724 μg/L with a median concentration of 7.62 μg/L. Manganese exceeded the 50.0 μg/L SMCL at 2 of the 7 sites (28.6 percent) sampled. Manganese concentrations ranged from a minimum of 1.93 μg/L to a maximum of 271 μg/L with a median concentration of 4.03 μg/L. No sites sampled exceeded the arsenic maximum contaminant level (MCL) of 10 μg/L. Arsenic concentrations ranged from a minimum of <0.100 μg/L to a maximum of 2.35 μg/L with a median arsenic concentration of 0.200 μg/L. None of the seven sites sampled for selenium for this study exceeded the EPA MCL of 50.0 μg/L. Selenium concentrations ranged from a minimum of <0.050 μg/L to a maximum of 5.26 μg/L with a median concentration of 3.21 μg/L.

All seven sites were sampled for volatile organic compounds (VOCs), semivolatile organic compounds (SVOCs), and polychlorinated biphenyls (PCBs), but most had concentrations below the detection limit. Of the 10 PCB compounds analyzed for the seven sites sampled, none contained detectable concentrations of PCBs or Aroclor compounds. Of the 44 SVOCs analyzed at each of the seven sites sampled, only 1 SVOC, acenaphthene, was detected, at a concentration of 0.02 μg/L. Of the 96 VOCs analyzed, from each of the seven sites sampled, only two were found at detectable concentrations. Trichloromethane was detected only at 1 of the 7 (14.3 percent) sites sampled at a concentration of 0.027 μg/L, and benzene was detected at the same site and 3 additional sites (4 of the 7 sites or 57.1 percent of the sites sampled) at concentrations of 0.028, 0.029, 0.021, and 0.035 μg/L, but none exceeded the EPA MCL for benzene of 5.00 μg/L.

Total coliform bacteria are ubiquitous in the environment, and their presence only suggests the potential for contamination by near-surface processes. Escherichia coli (E. coli) bacteria are derived from either human or animal fecal material and can be an indicator of potential contamination by pathogenic bacteria or viruses. Total coliform bacteria were detected at all 7 sites sampled at concentrations ranging from 17.5 to greater than (>) 2,420 most probable number per 100 mL (MPN/100 mL) of sample, with a median total coliform concentration of 1,553 MPN/100 mL. Escherichia coli bacteria were detected at 4 of the 7 sites sampled at concentrations ranging from <1 to 11.9 MPN/100 mL, with a median E. coli concentration of 5.1 MPN/100 mL.
