Thermal infrared investigations, Arbuckle Mountains, Oklahoma

Thermal-infrared images obtained on flights over the Tishomingo anticline and South Flank areas near Mill Creek in the Arbuckle Mountains, Oklahoma, were used to study the possibility of identifying some common rock types from their diagnostic reflection and emission characteristics, and to evaluate the usefulness of infrared images in structural geologic investigations. The areas flown are underlain by folded and faulted Paleozoic dolomite, limestone, sandstone, shale, and Precambrian granite.

Images were obtained at 6:00 a.m., 11:00 a.m., and 2:00 p.m. The predawn (6:00 a.m.) image is the most useful in distinguishing rock types. Of particular interest is a thermal contrast of dolomite (warm) and limestone (cool), sufficient to distinguish those rock types and to reveal facies changes between them. Theoretical considerations indicate that this thermal contrast arises from a combination of albedo and thermal-inertia characteristics distinctive of dolomites and limestones in many areas.

The daytime images display much stratigraphic and structural detail. Small-scale bedding detail is enhanced in the morning images of low-relief areas, and contrasts of alternating formations that form hogbacks and valleys are enhanced in the afternoon images of higher relief areas. The difference in features displayed in morning and afternoon images appears to be a function of the insolation on sunward and shadowed slopes of differing scale. Fault or fracture zones are best displayed in the predawn image; they appear cooler than surrounding ground, because of greater water content and concomitant evaporation. The abundance and throughgoing nature of lineaments (which coincide for the most part with joint systems) are more obvious in the infrared images than in aerial photographs. Lineaments striking northwest are preferentially enhanced in the morning images, and lineaments striking northeast are preferentially shown in the afternoon images. This enhancement cannot be ascribed to the effects of topography, insolation, or wind; it may relate to a combination of ground-water and vegetation effects.
