These data are high-resolution bathymetry (riverbed elevation) and depth-averaged velocities in comma-delimited table format, generated from hydrographic and velocimetric surveys near highway bridge structures over the Missouri River between Kansas City and St. Louis, Missouri, May 19–26, 2021. Hydrographic data were collected using a high-resolution multibeam echosounder mapping system (MBMS), which consists of a multibeam echosounder (MBES) and an inertial navigation system (INS) mounted on a marine survey vessel. Data were collected as the vessel traversed the river along planned survey lines distributed throughout the reach. Data collection software integrated and stored the depth data from the MBES and the horizontal and vertical position and attitude data of the vessel from the INS in real time. Data processing required specialized computer software to extract bathymetry data from the raw data files and to summarize and map the information.
Velocity data for the surveys were collected using an acoustic Doppler current profiler (ADCP) mounted on a survey vessel equipped with a differential global positioning system (DGPS). Velocity data were collected for all sites except site 14 at Lexington due to a faulty ADCP unit. Data were collected as the vessel traversed the river along seven planned transect lines distributed throughout the reach. Velocity data were processed using the Velocity Mapping Toolbox (Parsons and others, 2013), and smoothed using neighboring nodes.
There is a zip file for the 8 surveyed sites available for download containing the bathymetric data and depth-averaged velocities. The files follow the format of "site-##_MissouriRiver_HWY#_2021-05.zip", where "site-##" is the site number from 14 to 21 and "HWY#" is the highway type and route number. The zip files each contain two comma-delimited text files, one with the bathymetry and uncertainty data and one with the depth-averaged velocity data, as well as associated metadata and thumbnail images.
Parsons, D.R., Jackson, P.R., Czuba, J.A., Engel, F.L., Rhoads, B.L., Oberg, K.A., Best, J.L., Mueller, D.S., Johnson, K.K., and Riley, J.D., 2013, Velocity Mapping Toolbox (VMT) A process and visualization suite for moving-vessel ADCP measurements: Earth Surface Processes and Landforms, v. 38, no. 11, p. 1244-1260. [Also available at https://doi.org/10.1002/esp.3367.]
First posted May 10, 2023, ver. 1.0
Revised July 31, 2023, ver. 2.0
|Title||Bathymetry and Velocity Data from Surveys at Highway Bridges Crossing the Missouri River between Kansas City and St. Louis, Missouri, May 19–26, 2021|
|Authors||Richard J Huizinga, Benjamin C Rivers|
|Product Type||Data Release|
|Record Source||USGS Digital Object Identifier Catalog|
|USGS Organization||Central Midwest Water Science Center|
