Carbon dioxide flux measurements at and adjacent to the Sulphur Bank Mercury Mine, Clear Lake Volcanic Field, California

July 16, 2024

The 2.1 Ma Clear Lake Volcanic Field (Donnelly-Nolan and others, 1981) and the 174 km2 Clear Lake are located ~150 km north of San Francisco, California. Sulphur Bank Mercury Mine (SBMM) is an abandoned mine located on the eastern shore of Clear Lake that was initially worked in 1865 for sulfur, then for mercury until it closed in 1957 (White and Roberson, 1962). The mine was declared a Superfund site by the U.S. Environmental Protection Agency in 1990 because of the presence of mercury-bearing mine waste and mercury bioaccumulation in fish within Clear Lake. SBMM is underlain by a localized, fault-controlled, liquid-dominated hydrothermal system (Goff and others, 1995). Hydrothermal gases are rich in CO2 with a high contribution of mantle-derived He (Goff and Janik, 1993). We carried out surveys of CO2 flux from ground and water surfaces using the accumulation chamber method to characterize the spatial distribution of and quantify hydrothermal CO2 emissions. In an initial reconnaissance survey on February 1-2, 2023, we made 180 CO2 flux measurements across SBMM and an adjacent area east of the mine. Measured CO2 fluxes ranged from <1 to 42,624 g/m2 d, with the highest values observed in and near mine pits. Four hundred thirty-one CO2 fluxes were measured in follow-on surveys on May 8-11 and June 21, 2023, and ranged from <1 to 93,215 g/m2 d. The CO2 flux data measured in the reconnaissance and follow-on surveys are saved in two spreadsheets in the *.csv format.
References
Donnelly-Nolan, J.M., B.C. Jr. Hearn, G.H. Curtis, R.E. Drake, 1981. Geochronology and evolution of the Clear Lake volcanics. In: Research in The Geysers-Clear Lake Geothermal Area, Northern California. U.S. Geological Survey Professional Paper 1141, 47–60.
Goff, F.E., C.J. Janik, 1993. Gas geochemistry and guide for geothermal features in the Clear Lake region, California. In: Rytuba, J.J. (Ed.), Active Geothermal Systems and Gold-Mercury Deposits in the Sonoma-Clear Lake Volcanic Fields, California. Society Economic Geologists Guidebook Series, 16, 207–261.
Goff, F.E., C.J. Janik, J.A. Stimac, 1995. Sulphur Bank mine, California: an example of a magmatic rather than metamorphic hydrothermal system? Proceedings of the World Geothermal Congress, Florence, Italy, 2, 1105–1110.
White, D.E., C.E. Roberson, 1962. Sulphur Bank, California, a major hot-spring quicksilver deposit. Geological Society of America, Buddington Volume, 397-428.

Publication Year 2024
Title Carbon dioxide flux measurements at and adjacent to the Sulphur Bank Mercury Mine, Clear Lake Volcanic Field, California
DOI 10.5066/P9FFJ2VL
Authors Jennifer L Lewicki, Laura Clor
Product Type Data Release
Record Source USGS Asset Identifier Service (AIS)
USGS Organization USGS Volcano Science Center
Rights This work is marked with CC0 1.0 Universal
