Horizontal-to-Vertical Spectral Ratio and Depth-to-Bedrock for Geohydrology and Water Quality of the Stratified-Drift Aquifer in West Branch Cayuga Inlet and Fish Kill Valleys, Town of Newfield, Tompkins County, New York, July 2011 - November 2016

August 30, 2021

From July 2011 to November 2016, the U.S. Geological Survey, in cooperation with the Town of Newfield and the Tompkins County Planning Department, collected horizontal-to-vertical seismic surveys at 58 locations in the West Branch Cayuga Inlet and Fish Kill valleys to help determine thickness of unconsolidated deposits and depth to bedrock. The HVSR technique, commonly referred to as the passive-seismic method, is used to estimate the thickness of unconsolidated sediments and the depth to bedrock (Lane and others, 2008). The passive-seismic method uses a single, broad-band three-component (two horizontal and one vertical) seismometer to record ambient seismic noise. In areas that have a strong acoustic contrast between the bedrock and overlying sediments, the seismic noise induces resonance at frequencies that range from about 0.3 to 40 Hz. The ratio of the average horizontal-to-vertical spectrums produces a spectral-ratio curve with peaks at fundamental and higher-order resonance frequencies. The spectral ratio curve (the ratio of the averaged horizontal-to-vertical component spectrums) is used to determine the fundamental resonance frequency that can be used along with an average shear-wave velocity or a power-law regression equation to estimate sediment thickness and depth to bedrock (Lane and others, 2008; Brown and others, 2013; Fairchild and other, 2013; Chandler and others, 2014; and Johnson and Lane, 2016). The HVSR data presented in this data release was collected at each site for 30 minutes using a Tromino Model TEP-3C1 three-component seismometer. The data was processed with Grilla 2012 version. 6.21 software to 1) remove anthropogenic noise, 2) convert the time-domain data to frequency domain, 3) compute and plot the spectral ratio curve, and 4) determine the resonance frequency. This data release presents the resonance frequency peaks identified from the HVSR measurements. Also presented are reported depth-to-bedrock data for wells located at or near HVSR data-collection sites in the Town of Newfield for use in comparison of HVSR forward model depths to reported well depths. Raw and processed HVSR data for each HVSR measurement are presented in the attached. The HVSR data-collection sites are designated by a county sequential numbering system (TMHVSR8, TMHVSR9, etc. where TM indicates Tompkins County). 1Any use of trade, firm, or product names is for descriptive purposes only and does not imply endorsement by the U.S. Government.

Citation Information

Publication Year 2021
Title Horizontal-to-Vertical Spectral Ratio and Depth-to-Bedrock for Geohydrology and Water Quality of the Stratified-Drift Aquifer in West Branch Cayuga Inlet and Fish Kill Valleys, Town of Newfield, Tompkins County, New York, July 2011 - November 2016
DOI 10.5066/P9N6AZ4E
Authors Benjamin N Fisher, Paul M Heisig, William M Kappel
Product Type Data Release
Record Source USGS Digital Object Identifier Catalog
USGS Organization New York Water Science Center
