Terrestrial Laser Scanning Data from Malakoff Diggins State Historic Park, Nevada County, California, 2014-17.
October 31, 2019
High-resolution, terrestrial laser scanning (TLS), was used to quantify the volume of sediment eroded from outcrops at Malakoff Diggins State Historic Park, located about 17 kilometers (km) northeast of Grass Valley, California. TLS was used to create centimeter-scale, three-dimensional (3-D) maps of the complex outcrop surfaces, which could not be mapped non-destructively or in sufficient detail with traditional surveying techniques. To develop a comprehensive sediment budget for the Malakoff Diggins mine pit that will help identify sources of sediment and metals within the pit that comprise the suspended sediment discharged from the pit into Humbug Creek, the USGS used TLS technology to quantify the eroded volumes and erosion rates of sedimentary units exposed in the pit walls. Eroded volumes from nineteen sedimentary units at four study sites located throughout the pit were calculated for the period December 2014 to August 2017. (Note that the monitoring sites were numbered 1, 2, 4, and 5.) Each survey at all four study sites was comprised of multiple lidar scans collected from different vantages that were combined into a composite 3-D point cloud. At all four study sites, the sequential surveys were co-registered or 'aligned' into a common and site-specific reference frame so that volumetric comparisons between surveys could be made. At each study site, sedimentary units were differentiated based on grain size, color, compaction, cementation, and slope angle. The various sedimentary units were mapped on the lidar point clouds and individually isolated for volumetric change analysis. The volumetric differences between surveys quantify the erosional and/or depositional volume change of each sedimentary unit.
Citation Information
Publication Year | 2019 |
---|---|
Title | Terrestrial Laser Scanning Data from Malakoff Diggins State Historic Park, Nevada County, California, 2014-17. |
DOI | 10.5066/P9H3VNSN |
Authors | James F Howle |
Product Type | Data Release |
Record Source | USGS Asset Identifier Service (AIS) |
USGS Organization | Central Midwest Water Science Center |
Rights | This work is marked with CC0 1.0 Universal |
Related
Quantifying erosion rates by using terrestrial laser scanning at Malakoff Diggins State Historic Park, Nevada County, California, 2014–17
The abandoned hydraulic mine pit at Malakoff Diggins near Grass Valley, California, can produce large volumes of eroded sediment transportable by storm runoff. Sediment-laden water discharged from the pit is a major source of heavy metals to Humbug Creek and the South Yuba River. To develop a comprehensive sediment budget for the Malakoff Diggins mine pit and identify sources of sediment...
Authors
James F. Howle, Charles N. Alpers, Alfred J. Ward, Sandra Bond, Jennifer A. Curtis
Related
Quantifying erosion rates by using terrestrial laser scanning at Malakoff Diggins State Historic Park, Nevada County, California, 2014–17
The abandoned hydraulic mine pit at Malakoff Diggins near Grass Valley, California, can produce large volumes of eroded sediment transportable by storm runoff. Sediment-laden water discharged from the pit is a major source of heavy metals to Humbug Creek and the South Yuba River. To develop a comprehensive sediment budget for the Malakoff Diggins mine pit and identify sources of sediment...
Authors
James F. Howle, Charles N. Alpers, Alfred J. Ward, Sandra Bond, Jennifer A. Curtis
