Testing reproducibility of vitrinite and solid bitumen reflectance measurements in North American unconventional petroleum systems (2019)

December 17, 2021

To test reproducibility of vitrinite and solid bitumen reflectance measurements in mudrocks, an interlaboratory study (ILS) was conducted using six samples from United States unconventional petroleum systems. Samples selected from the Marcellus, Haynesville, Eagle Ford, Barnett, Bakken and Woodford are representative of resource plays currently under exploitation in North America. All samples are from marine depositional environments, are thermally mature (Tmax greater than 445 degrees Celsius) and have moderate to high organic matter content (2.9 to 11.6 wt.% TOC). The organic matter of the sample is dominated by solid bitumen, which contains intraparticle nano-porosity. Visual evaluation of organic nano-porosity via SEM suggests that intraparticle organic nanopores are most abundant in dry gas maturity samples and less abundant at lower wet gas/condensate and peak oil maturities. Samples were distributed to ILS participants in forty laboratories in the Americas, Europe, Africa and Australia; thirty- seven independent sets of results were received. Mean vitrinite reflectance (VRo) values from ILS participants range from 0.90 to 1.83% whereas mean solid bitumen reflectance (BRo) values range from 0.85 to 2.04% (no outlying values excluded), confirming the thermally mature nature of all six samples. Using multiple statistical approaches to eliminate outlying values, we evaluated reproducibility limit R, the maximum difference between valid mean reflectance results obtained on the same sample by different operators in different laboratories using different instruments. Removal of outlying values where the individual signed multiple of standard deviation was greater than 1.0 produced lowest R values, generally equal to or less than 0.5% (absolute reflectance), similar to a prior ILS for similar samples. Other traditional approaches to outlier removal (outside mean plus or minus 1.5*interquartile range and outside F10 to F90 percentile range) also produced similar R values. Standard deviation values less than 0.15*(VRo or BRo) reduce R and should be a requirement of dispersed organic matter reflectance analysis. R values were 0.1% to 0.2% for peak oil thermal maturity, about 0.3% for wet gas/condensate maturity and 0.4% to 0.5% for dry gas maturity. That is, these R values represent the uncertainty (in absolute reflectance) that users of vitrinite and solid bitumen reflectance data should assign to any one individual reported mean reflectance value from a similar thermal maturity mudrock sample. R values of this magnitude indicate a need for further standardization of reflectance measurement of dispersed organic matter. Furthermore, these R values quantify realistic interlaboratory measurement dispersion for a difficult but critically important analytical technique necessary for thermal maturity determination in unconventional petroleum systems.

Publication Year 2021
Title Testing reproducibility of vitrinite and solid bitumen reflectance measurements in North American unconventional petroleum systems (2019)
DOI 10.5066/P9LB8IJ4
Authors Mary R. Croke
Product Type Data Release
Record Source USGS Digital Object Identifier Catalog
USGS Organization Energy Resources Program Headquarters Office
