These maps are designed to give the general public as well as land-use planners, utilities and lifeline owners, and emergency response officials, new and better tools to assess their risk from earthquake damage. The maps also contribute to the California Geological Survey’s Seismic Hazard Zone maps.
The California Geological Survey has zoned the greater San Francisco area for liquefaction hazard in their seismic hazard maps and liquefaction-related regulatory maps.
Figure 1 is a map of the young geologic deposits in the low-lying sections of the Bay Area. It is important to map these deposits because so much of our infrastructure resides on them, and because they may host liquefaction, the phenomenon of saturated soils losing their stiffness and strength during shaking. Some of the young deposits strongly affect the strength of earthquake shaking that is transmitted through the deposits.
Figure 2 shows the likelihood that these young deposits will liquefy, or turn into a sandy liquid due to the strong shaking a big earthquake will produce. When the ground liquefies, it may lose its ability to support buildings and other structures. Liquefaction during large earthquakes commonly disrupts pipelines and road networks and also may cause buildings to settle and move downslope or toward stream banks.
Figure 3 shows that the shaking experienced in a region depends very strongly on the type of deposits found near the surface. Soft muds shake much harder than bedrock. Figure 4 shows part of the Cypress structure, the freeway approach to the Bay Bridge from Oakland, which collapsed during the Loma Prieta earthquake, killing 42 people. Soft muds on which it was constructed shook much more strongly than surrounding regions on stronger ground. Detailed mapping is needed to forecast where shaking will be strongest during future earthquakes.
We can expect history to repeat itself in the next big Bay Area earthquake.
The highest hazard areas shown by the liquefaction hazard maps are concentrated in regions of man-made landfill, especially fill that was placed many decades ago in areas that were once submerged bay floor. Such areas along the Bay margins are found in San Francisco, Oakland and Alameda Island, as well as other places around San Francisco Bay. Other potentially hazardous areas include those along some of the larger streams, which produce the loose young soils that are particularly susceptible to liquefaction.
These maps show a lower likelihood of liquefaction than previously thought in regions underlain by Bay mud that fringes many parts of San Francisco Bay. Bay mud remains a seismic hazard because on the basis of its past performance in earthquakes it will produce stronger levels of shaking than other geologic units.
The maps show in unprecedented detail the nature of the materials that underlie areas of densest urban development and highlight areas that may be prone to shaking-related damage during future earthquakes.
These maps are the result of over a decade of work and collaboration between geologists from the consulting firm William Lettis & Associates, the U.S. Geological Survey, and the California Geological Survey.
Many of the region’s utilities and lifeline owners have made use of an earlier version of these maps in vulnerability assessments of their systems.
These new maps cover the San Francisco Bay region (outlined in red). A previous USGS map, published in 2000, covers a larger region (outlined in black).
Northern San Francisco and the Marin peninsula are not included in the new maps because geologic field mapping in these regions is incomplete. Please use the older map for areas not covered by the new map. The older map also shows locations of liquefaction observed in historical earthquakes, particularly the Great 1906 earthquake and the 1989 Loma Prieta quake.
- Overview
These maps are designed to give the general public as well as land-use planners, utilities and lifeline owners, and emergency response officials, new and better tools to assess their risk from earthquake damage. The maps also contribute to the California Geological Survey’s Seismic Hazard Zone maps.
The California Geological Survey has zoned the greater San Francisco area for liquefaction hazard in their seismic hazard maps and liquefaction-related regulatory maps.
Sources/Usage: Public Domain.Figure 1. Quaternary Deposits from Maps of Quaternary Deposits and Liquefaction Susceptibility in the Central San Francisco Bay region, California, 2006 Figure 1 is a map of the young geologic deposits in the low-lying sections of the Bay Area. It is important to map these deposits because so much of our infrastructure resides on them, and because they may host liquefaction, the phenomenon of saturated soils losing their stiffness and strength during shaking. Some of the young deposits strongly affect the strength of earthquake shaking that is transmitted through the deposits.
Sources/Usage: Public Domain.Figure 2. Liquefaction Susceptibility from Maps of Quaternary Deposits and Liquefaction Susceptibility in the Central San Francisco Bay region, California, 2006 Figure 2 shows the likelihood that these young deposits will liquefy, or turn into a sandy liquid due to the strong shaking a big earthquake will produce. When the ground liquefies, it may lose its ability to support buildings and other structures. Liquefaction during large earthquakes commonly disrupts pipelines and road networks and also may cause buildings to settle and move downslope or toward stream banks.
Sources/Usage: Public Domain.Figure 3. Recordings of the shaking levels in three different areas in the San Francisco Bay from the Loma Prieta Earthquake show that the shaking experienced depends very strongly on the type of deposits found near the surface. Soft muds shake much harder than bedrock.
Sources/Usage: Public Domain.Figure 4. Side view of support-column failure and collapsed upper deck, Cypress viaduct. Figure 3 shows that the shaking experienced in a region depends very strongly on the type of deposits found near the surface. Soft muds shake much harder than bedrock. Figure 4 shows part of the Cypress structure, the freeway approach to the Bay Bridge from Oakland, which collapsed during the Loma Prieta earthquake, killing 42 people. Soft muds on which it was constructed shook much more strongly than surrounding regions on stronger ground. Detailed mapping is needed to forecast where shaking will be strongest during future earthquakes.
We can expect history to repeat itself in the next big Bay Area earthquake.
Sources/Usage: Public Domain.Figure 5. 1906 earthquake damage to home on Howard and 17th Streets in San Francisco. Liquefaction, the phenomenon of saturated soils losing their stiffness and strength during shaking, caused structures to tilt and collapse. The highest hazard areas shown by the liquefaction hazard maps are concentrated in regions of man-made landfill, especially fill that was placed many decades ago in areas that were once submerged bay floor. Such areas along the Bay margins are found in San Francisco, Oakland and Alameda Island, as well as other places around San Francisco Bay. Other potentially hazardous areas include those along some of the larger streams, which produce the loose young soils that are particularly susceptible to liquefaction.
These maps show a lower likelihood of liquefaction than previously thought in regions underlain by Bay mud that fringes many parts of San Francisco Bay. Bay mud remains a seismic hazard because on the basis of its past performance in earthquakes it will produce stronger levels of shaking than other geologic units.
The maps show in unprecedented detail the nature of the materials that underlie areas of densest urban development and highlight areas that may be prone to shaking-related damage during future earthquakes.
These maps are the result of over a decade of work and collaboration between geologists from the consulting firm William Lettis & Associates, the U.S. Geological Survey, and the California Geological Survey.
Sources/Usage: Public Domain. Visit Media to see details.Figure 6. An automobile lies crushed under the third story of this apartment building in the Marina District. The ground levels are no longer visible because of structural failure and sinking due to liquefaction. Many of the region’s utilities and lifeline owners have made use of an earlier version of these maps in vulnerability assessments of their systems.
These new maps cover the San Francisco Bay region (outlined in red). A previous USGS map, published in 2000, covers a larger region (outlined in black).
Northern San Francisco and the Marin peninsula are not included in the new maps because geologic field mapping in these regions is incomplete. Please use the older map for areas not covered by the new map. The older map also shows locations of liquefaction observed in historical earthquakes, particularly the Great 1906 earthquake and the 1989 Loma Prieta quake.
Sources/Usage: Public Domain.Figure 7. New vs Old Map Boundaries for Liquefaction Maps of San Francisco Bay Area (2006 versus 2000) - Publications
