1993 Annual Report: San Francisco estuary regional monitoring program for trace substances

This first annual report of the San Francisco Estuary Regional Monitoring Program contains the results of monitoring measurements made in 1993. Measurements of conventional water quality parameters and trace contaminant concentrations were made at 16 stations throughout the Estuary three times during the year: the wet period (March), during declining Delta outflow (May), and during the dry period (September). Water toxicity tests were conducted at 8 of those stations. Measurements of sediment quality and contaminant concentrations were made at the same 16 stations during the wet and dry sampling periods. Sediment toxicity was measured at 8 of those stations. Transplanted, bagged bivalve bioaccumulation and condition was measured at 11 stations during the wet and dry sampling periods.

Water Monitoring. Total or near-total (dissolved + particulate, see text) arsenic, cadmium, selenium, and dissolved (0.45 µm filtered) arsenic, cadmium, copper, nickel, silver, and zinc in water were highest in the South Bay. In general, dissolved metals in water were usually lowest in the Central Bay due to ocean influences. Near-total nickel and total mercury in water were highest in the northern estuary (San Pablo and Suisun Bays). Dissolved chromium and lead were highest at the Sacramento and San Joaquin River confluence stations. Six of the ten dissolved trace metals were highest in March during high runoff. Dissolved and total arsenic, selenium, and near-total cadmium were highest in September.

Concentrations of trace organic contaminants are reported for the March sampling period. Total PAHs and PCBs were highest in the South Bay, but PCBs were also high in the Napa River. Dissolved PAHs were highest in the Central Bay, and dissolved PCBs were highest in the Napa River. Total and dissolved pesticides were highest in the Sacramento River and in the Extreme South Bay.

Concentrations of trace elements in water (except selenium) were usually closely related with other environmental parameters. Total or near-total metals concentrations in water were most often associated with the amount of particulate material (TSS) in the water. Dissolved concentrations were usually associated with salinity or dissolved organic carbon (DOC) content. Dissolved PAHs were well correlated with TSS, but dissolved and total trace organic contaminants were poorly correlated with other water parameters.

Based on deviations from conservative mixing of fresh and salt water, three different patterns of possible sources of metals were identified in 1993. For dissolved chromium and lead, rivers and local runoff appeared to be important sources. For dissolved arsenic, cadmium, copper, and nickel year-round inputs from the South Bay appeared to be important sources. Dissolved mercury, selenium, and zinc were associated with local runoff in the South Bay during the wet period. Dissolved silver did not fit any of these patterns.

Although most contaminant concentrations were below water quality objectives, several trace contaminants were above the objectives at some stations. Comparisons to water quality objectives are used as a guide for evaluation of contaminant concentrations, but there are some differences in the way the RMP data are measured and that prescribed for regulatory purposes (see text). Concentrations of 5 metals in water were above EPA or Regional Basin Plan water quality objectives at six stations (see Table 30). Most of these elevated levels occurred at the northern estuary stations. Total PCB concentrations were above EPA human health objectives at all RMP stations. The pesticides chlordane, dieldrin, and DDTs were above the EPA objectives at several RMP stations, particularly at the northern-most, and river confluence stations.

Although some of the contaminant concentrations were above water quality objectives, water toxicity tests (96 hour algal growth and 48 hour bivalve larval development tests) did not indicate toxicity (sometimes inconclusive) associated with the water samples collected at any of the RMP stations in 1993. Exposure to Bay San Francisco Estuary Regional Monitoring Program Regional Monitoring Program 1993 Report ii water actually enhanced algal growth at most stations.

In addition to the Estuary-wide sampling, the Sacramento and San Joaquin Rivers were sampled upstream from their confluence. Stations in each river were sampled six times over a 6 week period of high flows. In the Sacramento River, seven of the ten dissolved metals measured had concentrations lower than those measured at the river confluence stations. Some metals concentrations in the San Joaquin River were higher, and some were lower than concentrations from the river confluence station. Metals concentrations in the Sacramento River were poorly related to river flow because the station at Rio Vista is under considerable tidal influence. In the San Joaquin River, flows were inversely related to 7 of 10 total metals concentrations.

Sediment Monitoring. Concentrations of silver, mercury, and lead in sediment were highest in the South Bay. However, concentrations of most trace metals in sediments were highest in the northern estuary at stations with the finest (silt, clay) sediments. The northern estuary stations with the coarsest (sand, shell) sediments generally had the lowest metals concentrations. There were differences in concentrations of cadmium, lead, and selenium in sediments between the sampling periods, but no consistent trend as to which sampling period had higher values. In September, PAHs and PCBs in sediments were highest in the Central Bay, but pesticides in sediments were highest in the northern estuary and Extreme South Bay.

NOAA’s Median Effects Ranges (ERM) for sediments were used as a guide for evaluation of sediment contaminant concentrations. Nickel was the only trace contaminant in sediment above the ERM guidelines, and it was high at all RMP stations. These high levels are probably due to natural, geologic sources.

Although sediment contaminant concentrations were below ERMs, sediment toxicity tests (10 day amphipod mortality, and 48 hour bivalve larval development in elutriates) indicated toxicity at all stations tested. Sediment factors that could have caused the toxicity were not investigated.

Bivalve Bioaccumulation. Mussels, oysters, and freshwater clams were transplanted to the RMP stations to evaluate bioaccumulation of trace substances. Trace metals were bioaccumulated at nearly all RMP stations. However, arsenic, lead, and mercury did not appear to bioaccumulate. There was generally more bioaccumulation during the dry season than during the wet season. In September, PAHs, PCBs, and pesticides accumulated in all samples. Bioaccumulation of PAHs and pesticides was generally highest at the river confluence stations, and the Napa River. PCBs accumulated most at Redwood Creek.

There were substantial differences in the degree of bioaccumulation among the species. Oysters appeared to accumulate higher concentrations of trace metals than the other species, especially copper, which may be a natural phenomenon.

There are no established tissue contaminant standards for trace metal and organic contaminants. Therefore, comparisons to Median International Standards (MIS) for human consumption, or U.S. Food and Drug Administration (USFDA) action levels for trace organics are used to evaluate the bioaccumulation results. Concentrations of selenium were higher than MIS guidelines at all stations during the wet season. Other trace metal concentrations were higher than MIS guidelines at various stations during one or the other sampling period. However, none of the bivalves contained concentrations above the USFDA or National Academy of Sciences (NAS) guidelines for trace organic contaminants.

The transplanted bivalves survived well at all stations except in the Napa River where less than 35% survived during both sampling seasons. Measures of bivalve condition (dry weight, shell volume) indicated that bivalves deployed in the Central Bay grew significantly, but those at most other stations actually lost weight. Whether these differences were due to natural causes such as salinity or food supply, or to contamination, was not determined.

Pilot Studies. Two pilot monitoring studies were conducted in 1993. A pilot study of Estuary hydrography and phytoplankton was conducted by scientists from the U.S. Summary Geological Survey in Menlo Park and U.C. Davis. Water column profiles at up to 37 stations were monitored along a transect of the Estuary run monthly between the South Bay and the Delta.

The primary objective of this study was to define physical (salinity, temperature, suspended particulate matter, and light penetration), chemical (dissolved oxygen) and biological (chlorophyll a) characteristics of Estuary water that may influence other chemical and biological reactions. A second objective was to investigate planktonic indicators of ecosystem structure and function.

The data collected in 1993 showed the extent and duration of the spring phytoplankton bloom in the South Bay, other localized blooms in the northern estuary, the stratification and mixing associated with the entrapment zone in the northern estuary, and mixing in the Estuary resulting from the high rainfall in 1993. Knowledge of the duration and extent of these natural features of the Estuary provide context for interpretation of the RMP contaminant data collected only 3 times per year.

Another pilot study of suspended sediment transport processes was conducted by the USGS in Sacramento. This study used continuous recording sensors at Point San Pablo and the Bay Bridge to measure the amount of suspended sediment in the water at mid-depth and near the bottom, as well as tide height.

The objectives of this study were to estimate which factors determine suspended solids concentrations in the Central Bay and to collect time series of suspended solids that are appropriate for continuous monitoring of suspended solids and for calibration and validation of numerical models.

The investigators determined that spring tides accounted for most of the variation in suspended solids concentrations at the stations monitored, not runoff from the Sacramento or San Joaquin Rivers, or semidiurnal and diurnal tides.

Comparisons were also made between measurements made by the continuous recordings and the RMP samples collected during the regular monitoring cruises. The different ways of measuring TSS were generally comparable, however only 3 measurements per year as made by the RMP could not provide the information of TSS variation actually occurring in the Estuary.

This information is important because as shown by the RMP data, total contaminant concentrations in Estuary water is largely dependent on the TSS in the water. This implies that the RMP measurements alone cannot determine accurately the range of contaminant concentrations without better characterizing the dynamics of TSS.

The RMP Pilot Studies are important to the developing RMP because they will help put RMP measurements into the perspective of Estuary processes and mechanisms at other time scales. The studies can relate those processes to the RMP measurements and will facilitate revision of sampling design and interpretation.

Summaries of other monitoring activities pertinent to regional monitoring are also included in the Report: a description of the Regional Board’s Bay Protection Studies, the Sacramento Coordinated Monitoring Program, and a wetlands monitoring plan are included.
