The acoustic streamflow-measuring system on the Columbia River at The Dalles, Oregon

Records of discharge on the Columbia River at The Dalles, Oreg., are vital to the management of the complex water-development projects in the Columbia River basin. Accurate discharge figures are needed for consistent day-to-day management and are required to meet treaty obligations with Canada.

Because dams have been erected that completely control watersurface elevations at nearly all points in the river from Bonneville Dam to the Canadian border, conventional stream-gaging methods, used historically, are no longer adequate. Consequently, new techniques must be used to obtain the accurate discharge records required--records that are computed independently from the hydroelectric operation logs and that stand alone as the recognized flow records in the basin.

This need for an accurate, independent gaging system has been met by the installation of an acoustic streamflow-measuring system in the river channel at The Dalles, Oreg. This device provides an index of water velocity by measuring the difference in traveltimes of acoustic pulses transmitted through the water in each direction along a diagonal path across the river. The flow of water along the path increases the speed of one signal and retards the speed of the other. The difference in time of travel is related linearly to the water velocity along the path. The velocity index and river stage are used as a two-variable index in the computation of flow. These variables, correlated against current-meter measurements made with specialized boat equipment, provide a reliable basis for computations of instantaneous and daily mean discharges.

Installation of this sytem, which is the first application of an AVM (acoustic velocity meter) in a large natural channel, was completed in April 1969. It has been in continuous operation since that date. Performance has been satisfactory, and similar installations at other key points in the Columbia River basin are now under consideration. This paper covers the general theory behind acoustic velocity meters, tracing development from earlier concepts to the present commercially available system. Conclusions are that the AVM can now be considered as an operational instrument which permits accurate gaging of river discharge at many sites where conventional stream-gaging procedures have proved to be unreliable.
