Aeromagnetic map of northwest Utah and adjacent parts of Nevada and Idaho

Two aeromagnetic surveys were flown to promote further understanding of the geology and structure in northwest Utah and adjacent parts of Nevada and Idaho by serving as a basis for geophysical interpretations and by supporting geological mapping, water and mineral resource investigations, and other topical studies. Although this area is in general sparsely populated, (except for cities and towns along the Wasatch Front such as Ogden and Brigham City), it encompasses metamorphic core complexes in the Grouse Creek and Raft River Mountains (figure 1) of interest to earth scientists studying Cenozoic extension. The region was shaken in 1909 and 1934 by M6+ earthquakes east of the Hansel Mountains (Doser, 1989; Arabasz and others, 1994); damage from the 1934 earthquake occurred as far east as Logan, Utah (http:// www.seis.utah.edu/lqthreat/nehrp_htm/1934hans/n1934ha1. shtml#urbse). The presence of Quaternary shield volcanoes and bimodal Pleistocene volcanism in Curlew Valley (Miller and others, 1995; Felger and others, 2016) as well as relatively high temperature gradients encountered in the Indian Cove drillhole in the north arm of Great Salt Lake (Blackett and others, 2014) may indicate some potential for geothermal energy development in the area (Miller and others, 1995). The area also hosts four significant mining districts, in the northern Pilot Range, the Goose Creek Mountains in the northwest corner of the map, the southern end of the Promontory Mountains, and the southwest part of the Raft River Mountains, although production notably waned after World War II (Doelling, 1980). Other prospects of interest include those in the southern Grouse Creek Mountains, Silver Island, and the northern Newfoundland Mountains.

Large areas of northwest Utah are covered by young, surficial deposits or by Great Salt Lake or are down-dropped into deep Cenozoic basins, making extrapolation of bedrock geology from widely spaced exposures difficult or tenuous (figure 1). Local spatial variations in the Earth's magnetic field (evident as anomalies on aeromagnetic maps) reflect the distribution of magnetic minerals, primarily magnetite, in the underlying rocks. In many cases the volume content of magnetic minerals can be related to rock type, and abrupt spatial changes in the amount of magnetic minerals commonly mark lithologic or structural boundaries. Magnetic data reflect magnetization variations within the crust and are well suited for mapping the distribution of mafic igneous rocks, although felsic igneous rocks, some mineralized zones, and other rock types also can produce measurable magnetic anomalies. For these reasons, the U.S. Geological Survey (USGS) and Utah Geological Survey (UGS) contracted for the collection of aeromagnetic data in this area.
