Analysis of alternative weir designs for improved passage of select fish at the U.S. Geological Survey streamgaging weir at Blackwells Mills, New Jersey

As the population of New Jersey continues to remain dense, the need for water supply will likely continue to be high, which can lead to water managers needing to make difficult decisions about managing drinking-water supply. Streamgaging weirs like the ones used by the U.S. Geological Survey (USGS) play a critical role in providing accurate and stable streamflow data, but their presence can affect the passage of diadromous fish species such as river herring (Alosa pseudoharengus [alewife], Alosa aestivalis [blueback herring], and Alosa sapidissima [American shad]). In some situations, weirs existing in rivers and streams are no longer used because they were part of a farm irrigation system or some type of industrial operation. The weir at the USGS streamgage 01402000 Millstone River at Blackwells Mills, New Jersey, was purposefully built as a hydraulic-control structure that provides a precise and stable control for the measurement of stage and computation of continuous streamflow. To satisfy the dual need of maintaining accurate streamflow data and providing improved fish passage for select species of fish during migration season, the USGS proposed the development and evaluation of two alternative weir designs that would meet the criteria established for successful passage of American shad, alewife, and blueback herring during their yearly migration. The designs were also required to maintain adequate control of the upstream pool elevation necessary for the precise computation of streamflow used by State agencies for municipal water-supply purposes for surrounding communities.

Two alternative weir design modifications were incorporated at the center of the Blackwells Mills weir and modeled using two-dimensional hydraulic modeling software and three-dimensional computational fluid-dynamics software to simultaneously evaluate conditions for passage of the target fish species and effects to streamflow computations at the streamgage. The models were calibrated to existing conditions around the weir location using surveyed-elevation data and recorded stage, streamflow, and velocity in the Millstone River. The alternative weir designs lowered the weir crest by 1.02 feet (ft) and the resulting simulations showed an effective increase in depth of 0.98 ft at the median streamflow of 251 cubic feet per second (ft³/s) and 0.96 ft at the 95-percent exceedance streamflow of 98 ft³/s. The alternative weir designs were also found to increase streamflow depth across the shallowest portions of the weir structure at the downstream anti-scour skirt by lowering the skirt about 4 inches, allowing for two or more body depths of water for American shad, alewife, and blueback herring at the median migration streamflow of 251 ft³/s. The alternative weir designs also reduced the highest stream velocities across the downstream weir sill and anti-scour skirt from about 9 to 10 feet per second, and the depth-averaged velocity to about 7 to 8 feet per second. The sensitivity of the weir with respect to the computation of streamflow was increased from about 1.8 cubic feet per second per hundredth foot to 1.6 cubic feet per second per hundredth foot for streamflows of about 10–100 cubic feet per second.
