Assessment of channel morphology, hydraulics, and bedload transport along the Siletz River, western Oregon

Significant Findings

Chinook salmon (Oncorhynchus tshawytscha) and Pacific lamprey (Entosphenus tridentatus) are native, anadromous fish species in the Siletz River Basin, western Oregon, that face many threats to their survival in freshwater and the ocean. The Confederated Tribes of Siletz Indians of Oregon seek to mitigate freshwater threats to Chinook salmon and Pacific lamprey, where possible, with habitat conservation and restoration efforts. This study was conducted to assist the Confederated Tribes of Siletz Indians of Oregon in documenting and understanding the hydrogeomorphic processes shaping present-day habitat conditions and assessing future habitat implications for Chinook salmon and Pacific lamprey along the main-stem Siletz River. As such, this study focused on understanding geomorphic processes and patterns of channel change, including lateral and vertical adjustments in channel position and changes in bed-material sediment (sands, gravels, and cobbles that mantle the channel bed), which collectively determine overall patterns of channel morphology and fluvial habitats. Objective One was to evaluate lateral changes in channel position, vertical changes in bed elevation, and longitudinal patterns in bed-material particle size along the Siletz River using detailed channel maps developed from aerial photographs collected from 1939 to 2016, long-term records of stage and discharge collected by the U.S. Geological Survey (USGS) near the City of Siletz, and sediment particle size data. Objective Two was to assess hydraulic conditions using one- and two-dimensional hydraulic models and transport capacity of bed-material sediment using bedload transport models and sediment particle size data for a range of discharge conditions. Objective Three was to identify potential burrowing habitat for lamprey larvae (PBH) along the Siletz River network and provide insights in local factors influencing PBH along the main-stem Siletz River. The overall findings are synthesized to describe habitat implications for Chinook salmon and Pacific lamprey under present-day and future conditions.

Results of Objective One, an evaluation of changes in channel position and bed elevations and longitudinal patterns in bed-material particle size along the Siletz River, include the following

• From 1939 to 2016, channel planform and the mapped area of gravel bars did not change considerably along the 97.2-kilometers (km) of Siletz River between Elk Creek and Millport Slough, except for in short sections generally less than 1 km long. This inherent lateral channel stability results from the resistant bedrock and terraces that bound most of the channel and limit lateral changes in channel position. Intermittent sections along the study reach where the active channel widened at channel bends displayed noticeable planform changes and increases in mapped bar area.
• From water year (WY; a 12-month period from October 1 through September 30 and named for the year in which it ends) 1906 to 2021, changes in the stage-discharge relation interpreted as rising and lowering channel bed levels were observed at the USGS streamgage 14305500 (Siletz River at Siletz, OR) in response to floods (such as high flows in February 1996 and January 2002 that exceeded 0.1 and 0.667 annual exceedance probabilities [AEP] events, respectively). However, the rating curve representing the stage-discharge relation did not change in response to high-magnitude floods between 2007 and 2021.
• Along the approximately 54-km of the Siletz River between Moonshine Park and the Bulls Bag area, surficial particle distributions varied considerably between sampling sites in response to changes in channel width and gradient, sediment inputs from tributaries, and basin geology. Despite this variability, median particle sizes tended to decrease in size in the downstream direction over the 54 km.

Results of Objective Two, an evaluation of hydraulic and bedload transport conditions along the Siletz River, include the following

• The most substantial increases in maximum and mean water velocity and bedload sediment transport capacity occurred at events between the 0.995 and 0.50 AEPs. Events of these magnitudes occur approximately every 1–2 years. Smaller events (0.995 AEP) are generally contained by the banks of the main channel, whereas larger events (0.50 AEP) generally spill over the banks and inundate high-elevation bar and low-elevation floodplain surfaces.
• Multiple smaller floods within a WY that exceed the 0.995 and 0.50 AEPs (such as in WY 1996) can transport as much or more bed-material sediment than a single, higher magnitude event (such as the maximum event recorded in WY 2000 with an estimated AEP of around 0.002).
• Bedload transport capacity generally exceeds sediment supply (greater than 2 millimeters [mm]) for most of the study area from Wildcat Creek to the City of Siletz as evidenced by substantial in-channel bedrock. Despite overall conditions of limited sediment supply, transport capacity still varies considerably within and between years with discharge magnitude and spatially in relation to local hydraulics imposed by bedrock, channel morphology, and human infrastructure (such as bridges).

Results of Objective Three, an analysis of PBH for lamprey larvae, include the following

• About 28 percent of the Siletz River network meets the mean annual suspended sediment loads and channel slope criteria for PBH. Along the main-stem Siletz River, in-channel bedrock outcrops and high transport capacity are expected to further constrain PBH.

Together, these results suggest that most of the Siletz River between Wildcat Creek and the City of Siletz has had only modest vertical and lateral change between the 1930s and 2010s because of the bedrock in and along the main channel and the river’s relatively high transport capacity relative to bed-material sediment supply. However, localized sections of the Siletz River where the active channel widens, particularly at channel bends, exhibited some change in channel planform and the locations and area of gravel bars. In the future, moderate increases in autumn-winter discharge may not result in substantial changes in coarse gravel bars along the Siletz River but may result in selective transport of finer bed-material sediment (gravel, sands, and silts) that provide spawning habitats for Chinook salmon and Pacific lamprey and burrowing habitats for lamprey larvae. Assuming no substantial changes in bed-material sediment supply, increased bedload transport capacity may cause frequent entrainment of lamprey larvae that are burrowed in coarse sand deposits, suspension and downstream transport of salmon eggs incubating in gravels, and reductions in the areas of spawning gravels for Chinook salmon and Pacific lamprey. Exact implications of current and future discharge conditions for these species along the Siletz River depends on many factors, including sediment supply, local hydraulics, and the timing of flood events relative to fish life stages.
