Assessment of effects of channelization mitigation alternatives of Stoney Brook, Carlton and St. Louis Counties, Minnesota

The U.S. Geological Survey, in cooperation with the Fond du Lac Band of Lake Superior Chippewa (FDLB), studied the effects of channel modification alternatives on lake levels and floodplain inundation in the Stoney Brook watershed in northeast Minnesota. Northern wild rice (Zizania palustris), also referred to as manoomin by the Ojibwe/Chippewa people, is a natural and cultural resource to the FDLB and is sensitive to water levels and rates of water-level changes, particularly during the early stages of growth. Drainage ditches constructed in the early 1900s in the Stoney Brook watershed lowered lake-water levels, caused greater fluctuations in the lakes, and created a loss in wetland coverage. The FDLB is committed to minimizing large fluctuations of the lakes with natural wild rice production in the Stoney Brook watershed and restoring a more natural hydrology to Stoney Brook. The hydrologic response of these lakes and floodplain storage to simulated channel modification alternatives were examined.

Hydrologic and hydraulic models were developed for the watershed and calibrated to historical rainfall events. The models used probabilistic frequency rainfall events of 24-hour duration for 1-, 2-, 5-, and 10-year annual recurrence intervals (100-, 50-, 20-, and 10-percent annual exceedance probability) to simulate watershed management scenarios with existing and alternative conditions. The hydraulic model outputs for peak flows, volume accumulation, water levels, and inundation duration and depths were assessed to quantify the effects of the channel modification alternatives. The channel modification alternatives were simulated with four different terrain conditions: existing conditions, bank spoil breach, original channel reconnection, and original channel reconnection with bank spoil breach. Hydrologic characteristics from six distinct areas were used in the model to evaluate the effects from the channel modification alternatives.

The simulated results of two lakes in which wild rice was planted demonstrated that the lakes would take longer to draw down following an event with the channel modification alternatives compared to existing conditions with little change to peak water-surface elevations. The alternatives provided minor to no increases in flows or conveyances at the downstream reference location at Pine Drive bridge. The restored floodplain locations had increased flows and conveyances for the channel modification alternatives that could be considered substantial when compared to flows with existing conditions. The inundation extent, duration, and water-depth distribution were assessed within selected floodplain areas. Generally, the channel modification alternatives produced increases in the higher depth (3–4 and greater than 4 feet) and duration (10–14 and greater than 14 days) categories for these areas, which may be beneficial to increases in wetland coverage and floodplain storage.
