Coastal bathymetry data collected in 2013 from the Chandeleur Islands, Louisiana

January 12, 2017

As part of the Barrier Island Evolution Research Project, scientists from the U.S. Geological Survey (USGS) St. Petersburg Coastal and Marine Science Center conducted nearshore geophysical surveys around the northern Chandeleur Islands, Louisiana, in July and August of 2013. The objective of the study is to better understand barrier-island geomorphic evolution, particularly storm-related depositional and erosional processes that shape the islands over annual to interannual timescales (1‒5 years). Collecting geophysical data will allow us to identify relationships between the geologic history of the island and its present day morphology and sediment distribution. This mapping effort was the third in a series of three planned surveys in this area. High resolution geophysical data collected in each of three consecutive years along this rapidly changing barrier island system will provide a unique time-series dataset that will significantly further the analyses and geomorphological interpretations of this and other coastal systems, improving our understanding of coastal response and evolution over short time scales (1‒5 years).

This data series includes the geophysical data that were collected during two cruises (USGS Field Activity Numbers (FAN) 13BIM02, 13BIM03, and 13BIM04, in July 2013; and FANs 13BIM07 and 13BIM08 in August 2013) aboard the R/V Sallenger, the R/V Jabba Jaw, and the R/V Shark along the northern portion of the Chandeleur Islands, Breton National Wildlife Refuge, Louisiana. Primary data were acquired with the following equipment: (1) a Systems Engineering and Assessment, Ltd., SWATHplus interferometric sonar (468 kilohertz [kHz]), (2) an EdgeTech 424 (4‒24 kHz) chirp sub-bottom profiling system, and (3) two Odom Hydrographic Systems, Incorporated, Echotrach CV100 single beam echosounders.

This data series report serves as an archive of processed interferometric swath and single-beam bathymetry data. Geographic information system data products include an interpolated digital elevation model, trackline maps, and point data files. Additional files include error analysis maps, Field Activity Collection System logs, and formal Federal Geographic Data Committee metadata.

Publication Year 2017
Title Coastal bathymetry data collected in 2013 from the Chandeleur Islands, Louisiana
DOI 10.3133/ds1032
Authors Nancy T. DeWitt, Jennifer L. Miselis, Jake J. Fredericks, Julie Bernier, Billy J. Reynolds, Kyle W. Kelso, David M. Thompson, James G. Flocks, Dana S. Wiese
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 1032
Index ID ds1032
Record Source USGS Publications Warehouse
USGS Organization St. Petersburg Coastal and Marine Science Center
