Correlation of flows at pairs of streamgages were evaluated using a Spearman’s rho correlation coefficient to better identify gages that can be used as index gages to estimate daily flow at ungaged stream sites in West Virginia. Much of West Virginia (77 percent) is within areas where Spearman’s rho for daily streamflow between streamgages on unregulated streams (unregulated streamgages) is greater than 0.9; most withdrawals from ungaged streams for shale gas well hydraulic fracturing are being made in these areas. Most of West Virginia (>99 percent) is within zones where Spearman’s rho between streamgages on unregulated streams is greater than 0.85. Withdrawals for hydraulic fracturing are made from ungaged streams in areas where Spearman’s rho between streamgages on unregulated streams is less than 0.9, but because spatial correlation is partly a function of the density of the streamgaging network, adding or reactivating several streamgages would be likely to result in correlations of 0.90 or higher in these areas.
Seasonal differences in the strength and spatial extent of correlations of daily streamflows are great. The strongest correlations among streamgages are for fall, followed by spring, then winter. One possible explanation for the weak correlations for summer may be that precipitation and runoff associated with convective storms affect one basin and miss nearby basins. A comparison of correlation patterns during previously identified climatic periods shows that the strongest correlations occurred during 1963–69, a period of drought, and the weakest during 1970–79, a wet period. The apparent effect of frequent rain during 1970–79 overshadowed streamgage-network density, which was at its historic maximum in West Virginia at that time, so that the extent of areas with high correlation to at least one streamgage was smaller during 1970–79 than during 1963–69. Correlations for 1992 to 2011 were slightly weaker than those for 1963 to 1969.
The relation between correlation and distance between basin centroids was determined to be stronger for streamgage pairs in the Ohio River Basin than for pairs in the Atlantic Slope River Basins, which in turn was stronger than the relation between pairs of streamgages split between the two major basins. Quantile regression equations were developed for these three comparisons to estimate the Spearman’s rho correlation coefficient for streamgage pairs using distance between basin centroids as a predictor variable. The equations can be used for streamgage network planning. For the Ohio River Basin, the distance between basin centroids at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.95 is 9 miles. The distance between basin centroids at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.90 is 25 miles, and the distance at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.85 is 48 miles. For the Atlantic Slope River Basins, the distance between basin centroids at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.95 is 1 mile. The distance between basin centroids at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.90 is 13 miles, and the distance at which 50 percent of streamgage pairs would exceed a Spearman’s rho of 0.85 is 41 miles. For pairs of streamgages split between the two major basins, the regression equation gives a value of 0.84 for the correlation coefficient at zero miles. On maps of correlations, the shape of strongly correlated areas for streamgages in the Ohio River Basin is generally round. In the Valley and Ridge Physiographic Province, which generally coincides with the Atlantic Slope River Basins within the study area, areas strongly correlated with streamgages generally coincide with major valleys.
|Title||Correlations of daily flows at streamgages in and near West Virginia, 1930-2011, and streamflow characteristics relevant to the use of index streamgages|
|Authors||Terence Messinger, Katherine S. Paybins|
|Publication Subtype||USGS Numbered Series|
|Series Title||Scientific Investigations Report|
|Record Source||USGS Publications Warehouse|
|USGS Organization||West Virginia Water Science Center|
