Flood-inundation maps for Fourmile Creek at Silver Grove, Kentucky

Digital flood-inundation maps for a 3.4-mile reach of Fourmile Creek at Silver Grove, Kentucky, were created by the U.S. Geological Survey (USGS) in cooperation with the City of Silver Grove and the U.S. Army Corps of Engineers Louisville District. Because the City of Silver Grove is subject to flooding from Fourmile Creek and the Ohio River (backwater flooding up Fourmile Creek), a set of flood-inundation maps was created, including maps for each flooding source considered independently and for possible scenarios involving flooding from both sources combined. The flood-inundation maps depict estimates of the areal extent and depth of flooding corresponding to a range of gage heights (gage height is commonly referred to as “stage,” or the water-surface elevation at a streamgage) at the USGS streamgage on Fourmile Creek at Grays Crossing at Silver Grove, Ky. (station number 03238785), and the USGS streamgage on Fourmile Creek at Highway 8 at Silver Grove, Ky. (station number 03238798). Near-real-time stages at these streamgages can be obtained from the USGS National Water Information System at https://waterdata.usgs.gov/. The USGS streamgage on the Ohio River at Cincinnati, Ohio (station number 03255000), is also important in this study because the National Weather Service (NWS) Advanced Hydrologic Prediction Service (AHPS; https://water.weather.gov/ahps/) forecasts flood hydrographs for this site (NWS AHPS site CCNO1). The peak-stage information forecast by the NWS AHPS can be used in conjunction with the maps developed in this study to show predicted areas of flood inundation.

Flood profiles were computed for the Fourmile Creek study reach by means of a one-dimensional, step-backwater hydraulic model (HEC-RAS) developed by the U.S. Army Corps of Engineers. The hydraulic model was calibrated by using the current stage-discharge relation (USGS rating number 1.1) at USGS streamgage 03238785, Fourmile Creek at Grays Crossing at Silver Grove, Ky. The model was then used to compute water-surface profiles for 83 combinations of flood stages on the Ohio River and Fourmile Creek ranging from approximately base flow to greater than a 2-percent annual exceedance probability flood in the model reach. An additional 50 water-surface profiles were computed for backwater-only flooding (from the Ohio River) for flood elevations (referenced to the North American Vertical Datum of 1988 [NAVD 88]) at 1-foot intervals referenced to USGS streamgage 03238798, Fourmile Creek at Highway 8 at Silver Grove, Ky.; these elevations ranged from approximately normal pool (460 ft, NAVD 88) to approximately a 0.2-percent annual exceedance probability flood (509 ft, NAVD 88) on the Ohio River. The computed water-surface profile information was then combined with a digital elevation model derived from light detection and ranging (lidar) data to delineate the approximate flooded areas.

The digital flood-inundation maps are available through the USGS Flood Inundation Mapper application (https://fim.wim.usgs.gov/fim/), which presents map libraries and provides detailed information on flood extent and depths for selected sites. The flood-inundation maps developed in this study, in conjunction with the real-time stage data from the USGS streamgages on Fourmile Creek at Silver Grove, Ky., and forecasted stream stages from the NWS AHPS, are intended to provide information that can help inform the public about potential flooding and provide emergency management personnel with a tool to efficiently manage emergency flood operations, such as evacuations and road closures, and assist in postflood recovery efforts.
