Geochemistry, Comparative Analysis, and Physical and Chemical Characteristics of the Thermal Waters East of Hot Springs National Park, Arkansas, 2006-09
A study was conducted by the U.S Geological Survey in cooperation with the Arkansas State Highway and Transportation Department to characterize the source and hydrogeologic conditions responsible for thermal water in a domestic well 5.5 miles east of Hot Springs National Park, Hot Springs, Arkansas, and to determine the degree of hydraulic connectivity between the thermal water in the well and the hot springs in Hot Springs National Park. The water temperature in the well, which was completed in the Stanley Shale, measured 33.9 degrees Celsius, March 1, 2006, and dropped to 21.7 degrees Celsius after 2 hours of pumping - still more than 4 degrees above typical local groundwater temperature. A second domestic well located 3 miles from the hot springs in Hot Springs National Park was discovered to have a thermal water component during a reconnaissance of the area. This second well was completed in the Bigfork Chert and field measurement of well water revealed a maximum temperature of 26.6 degrees Celsius. Mean temperature for shallow groundwater in the area is approximately 17 degrees Celsius. The occurrence of thermal water in these wells raised questions and concerns with regard to the timing for the appearance of the thermal water, which appeared to coincide with construction (including blasting activities) of the Highway 270 bypass-Highway 70 interchange. These concerns were heightened by the planned extension of the Highway 270 bypass to the north - a corridor that takes the highway across a section of the eroded anticlinal complex responsible for recharge to the hot springs of Hot Springs National Park.
Concerns regarding the possible effects of blasting associated with highway construction near the first thermal well necessitated a technical review on the effects of blasting on shallow groundwater systems. Results from available studies suggested that propagation of new fractures near blasting sites is of limited extent. Vibrations from blasting can result in rock collapse for uncased wells completed in highly fractured rock. However, the propagation of newly formed large fractures that potentially could damage well structures or result in pirating of water from production wells appears to be of limited possibility based on review of relevant studies.
Characteristics of hydraulic conductivity, storage, and fracture porosity were interpreted from flow rates observed in individual wells completed in the Bigfork Chert and Stanley Shale; from hydrographs produced from continuous measurements of water levels in wells completed in the Arkansas Novaculite, the Bigfork Chert, and Stanley Shale; and from a potentiometric-surface map constructed using water levels in wells throughout the study area. Data gathered from these three separate exercises showed that fracture porosity is much greater in the Bigfork Chert relative to that in the Stanley Shale, shallow groundwater flows from elevated recharge areas with exposures of Bigfork Chert along and into streams within the valleys formed on exposures of the Stanley Shale, and there was no evidence of interbasin transfer of groundwater within the shallow flow system.
Fifteen shallow wells and two cold-water springs were sampled from the various exposed formations in the study area to characterize the water quality and geochemistry for the shallow groundwater system and for comparison to the geochemistry of the hot springs in Hot Springs National Park. For the quartz formations (novaculite, chert, and sandstone formations), total dissolved solids concentrations were very low with a median concentration of 23 milligrams per liter, whereas the median concentration for groundwater from the shale formations was 184 milligrams per liter. Ten hot springs in Hot Springs National Park were sampled for the study. Several chemical constituents for the hot springs, including pH, total dissolved solids, major cations and anions, and trace metals, show similarity with the shale formations
Citation Information
Publication Year | 2009 |
---|---|
Title | Geochemistry, Comparative Analysis, and Physical and Chemical Characteristics of the Thermal Waters East of Hot Springs National Park, Arkansas, 2006-09 |
DOI | 10.3133/sir20095263 |
Authors | Timothy M. Kresse, Phillip D. Hays |
Publication Type | Report |
Publication Subtype | USGS Numbered Series |
Series Title | Scientific Investigations Report |
Series Number | 2009-5263 |
Index ID | sir20095263 |
Record Source | USGS Publications Warehouse |
USGS Organization | Arkansas Water Science Center |
