Geology and assessment of coal resources for the Cherokee coal bed in the Fort Union Formation, south-central Wyoming

The Cherokee coal bed is a locally thick and laterally continuous coal bed in the Overland Member of the Paleocene Fort Union Formation in south-central Wyoming. It represents a significant resource that is easily accessible and may be extractable through both surface and underground mining methods. A database of more than 600 data points, comprising coalbed methane wells, coal exploration drill holes, and measured sections, was compiled from a previously released geologic database and reinterpreted to provide a more detailed geologic model for the Cherokee coal bed. The thickest part of the Cherokee coal bed lies along the crest of the Wamsutter arch, an east-west trending anticlinal feature that separates the Great Divide subbasin to north from the Washakie subbasin to the south. The Cherokee coal bed consists of several laterally persistent benches separated by partings that range in thickness from one inch to greater than 100 feet. A series of detailed geologic cross sections through the study area show both the structural geology and the distribution and areal extent of the individual coal benches of the Cherokee coal bed.

Data generated from the geologic model were used in stochastic geostatistical analyses to estimate the remaining or in-place coal resources. Certain parameters, as described later in the text, were applied to calculate available coal resources for surface and underground mining. This study is part of an ongoing process by the U.S. Geological Survey (USGS) to transition from a distance-based approach to a probabilistic approach for determining uncertainty in coal resource assessment. This probabilistic approach uses quantitative statistical methods to determine the potential range of uncertainty in coal resource estimates, whereas the distance-based approach does not provide any mathematical method to determine the range of uncertainty. Using stochastic geostatistical methods, utilizing 100 realizations or gridding iterations of the data, in-place resources were calculated, with a 90 percent probability, to be 15.261 ± 0.464 billion short tons (bst). Available coal resources tonnages were calculated using separate sets of criteria for surface and underground mining methods, based on probable mining parameters. Tonnage values were calculated based on estimated coal densities determined from available coal quality data. Available coal resources that meet the parameters for surface mining methods were calculated, with a 90 percent probability, to be 0.813 ± 0.038 bst.

Available coal resources that meet the parameters for underground mining methods were calculated, with a 90 percent probability, to be 2.393 ± 0.055 bst. The calculations were based on estimates of the resources that meet the parameters for the optimum mining of the thickest coal benches of the Cherokee coal bed. This is depicted in a series of cross sections through the study area that show projected underground mining horizons in the Cherokee coal bed, based on the thickest combinations of individual coal benches.
