Helium-carbon systematics of groundwaters in the Lassen Peak Region

September 23, 2021

Carbon dioxide emissions from active subaerial volcanoes represent 20–50% of the annual global volcanic CO2 flux (Barry et al., 2014). Passive degassing of carbon from the flanks of volcanoes, and the associated accumulation of dissolved inorganic carbon (DIC) within nearby groundwater, also represents a potentially important, yet poorly constrained flux of carbon to the surface (Werner et al., 2019). Here we investigate sources and sinks of DIC in groundwaters in the Lassen Peak region of California. Specifically, we report and interpret the relative abundance and isotopic composition of helium (3He, 4He) and carbon (12C, 13C, 14C) in 37 groundwater samples, from 24 distinct wells, collected between 20 and 60 km from Lassen Peak. Measured groundwater samples have air-corrected 3He/4He values between 0.19 and 7.44 RA (where RA = air 3He/4He = 1.39 × 10−6), all in excess of the radiogenic production value (~0.05 RA), indicating pervasive mantle-derived helium additions to the groundwater system in the Lassen Peak region. Stable carbon isotope ratios of DIC (δ13C) vary between −12.6 and − 27.7‰ (vs. VPDB). Measured groundwater DIC/3He values fall in the range of 2.2 × 1010 to 1.1 × 1012. Using helium and carbon isotope data, we explore several conceptual models to estimate surface carbon contributions and to differentiate between DIC derived from soil CO2 versus DIC derived from external (slab and mantle) carbon sources. Specifically, if we use 14C to identify soil-derived DIC (assuming decadal-to-centennial groundwater ages and a soil CO2 14C activity equal to that of the atmosphere), we calculate that a hypothetical external carbon source would have an apparent δ13C signature between −10.3 and − 59.3‰ (vs. Vienna Pee Dee Belemnite (VPDB)) and an apparent C/3He between 7.0 × 109 and 1.0 × 1012. These apparent δ13C and C/3He values are substantially isotopically lighter than and greater than canonical MORB values, respectively. We suggest that >95% of any external (non-soil-derived) DIC in groundwater must thus be non-mantle in origin (i.e., slab derived or assimilated organic carbon). We further investigate possible sources of external DIC to groundwater using two idealized conceptual approaches: a pure (unfractionated) source mixing model (after Sano and Marty, 1995) and a scenario that invokes fractionation due to calcite precipitation. Because the former model requires carbon contributions from an organic source component with unrealistically low δ13C (~ − 60‰), we suggest that the second scenario is more plausible. Importantly, however, we caution that all conceptual models are dependent on assumptions about initial 14C activity. Thus, we cannot rule out the possibility that the true fraction of non-surface-derived DIC in these samples is lower or negligible, despite the pervasive mantle-derived He isotope signatures throughout the region. Following the 14C approach to deconvolving sources of DIC, we determine that the maximum passive carbon flux could be up to ~2.2 × 106 kg/yr, which is lower than previous magmatic carbon flux estimates from the Lassen region (Rose and Davisson, 1996). We find that the passive dissolved carbon flux could represent a maximum of ~4–18% of the total Lassen geothermal CO2 degassing flux (estimated to be ~3.5 × 107 kg/yr Rose and Davisson, 1996; Gerlach et al., 2008), which is still more than an order of magnitude smaller than soil gas CO2 flux estimates (7.3–11 × 107 kg/yr) for nearby volcanoes (Sorey et al., 1998; Gerlach et al., 1999; Evans et al., 2002; Werner et al., 2014). We conclude that passive dissolved carbon fluxes should be combined with geothermal fluxes and soil gas fluxes to obtain a complete picture of volcanic carbon emissions globally. Our approach highlights the utility of measuring helium isotopes in concert with the full suite of noble gas abundances, tritium, δ13C and 14C, which when interpreted together can be used to better elucidate the various sources of DIC in groundwater.

Citation Information

Publication Year 2021
Title Helium-carbon systematics of groundwaters in the Lassen Peak Region
DOI 10.1016/j.chemgeo.2021.120535
Authors Peter Barry, David Bekaert, John Krantz, Saemundor Halldorsson, J. Maarten DeMoor, Tobias Fischer, Cynthia Werner, Peter J. Kelly, Alan Seltzer, Brian Franz, Justin T. Kulongoski
Publication Type Article
Publication Subtype Journal Article
Series Title Chemical Geology
Index ID 70225164
Record Source USGS Publications Warehouse
USGS Organization Volcano Science Center
