Hydrodynamic assessment data associated with the July 2010 line 6B spill into the Kalamazoo River, Michigan, 2012–14

Hydrodynamic-assessment data for the Kalamazoo River were collected by the U.S. Geological Survey (USGS) during 2012–14 to augment other hydrodynamic data-collection efforts by Enbridge Energy L.P. and the U.S. Environmental Protection Agency associated with the 2010 Enbridge Line 6B oil spill. Specifically, the USGS data-collection efforts were focused on additional background data needed for 2013–14 updates to Enbridge’s 2012 hydrodynamic and sediment-transport models for simulating resuspension and deposition of submerged oil. The main data-collection activities consisted of the following along the Kalamazoo River: (1) a survey done by use of a Real-Time Network Global Navigation Satellite System, (2) water-level measurements in impounded sections, (3) velocity, discharge, and bathymetry measurements at transects and stationary points along the oil-affected reach of the river and in Morrow Delta and Lake, (4) estimates of tributary inflows, and (5) suspended-sediment concentrations and particle-size data at USGS streamgages along the Kalamazoo River. The method used to estimate bed shear stress from stationary velocity data is described. Averaged transect-based velocity data that were processed to match model grids also are included. In addition to model inputs and checks, these hydrodynamic-related data were used in submerged oil containment and recovery operations focused in impoundments and designated sediment traps. This report contains a description of the scope and methods associated with the hydrodynamic data collection and supplementary files of the USGS data that were used in modeling activities.
