Hydrous pyrolysis of New Albany Shale: A study examining maturation changes and porosity development

October 8, 2021

The characterization of nanoscale organic structures has improved our understanding of porosity development within source-rock reservoirs, but research linking organic porosity evolution to thermal maturity has generated conflicting results. To better understand this connection, an immature (0.25% solid bitumen reflectance; BRo) sample of the New Albany Shale was used in four isothermal hydrous pyrolysis (HP) experiment sequences at 300°, 320°, 340°, and 370°C, with residues collected periodically for a maximum of 103 days. The HP residues, along with the original immature sample and two naturally matured (1.49 and 1.56% BRo) New Albany Shale samples were analyzed for organic petrology, total organic carbon (TOC) content, and organic porosity evaluation using correlative light and electron microscopy (CLEM). All of the HP series increased in thermal maturity with increasing duration of pyrolysis, though reflectance for each series plateaued within 25 days of maturation. Initially, TOC in the HP residues decreases (from 14.24 wt. %) with increasing thermal maturity until ∼1.0% BRo where TOC remains at ∼9–10 wt. % for all remaining residues. Qualitative CLEM observations within the 50–100 day 300° and 340°C HP sequences (0.95–1.70% BRo), and the naturally matured samples, develop organic porosity in smaller (<5 μm in diameter), void-filling solid bitumen that occurs in spaces between clays and other fine-grained minerals. The 370°C HP residues developed significant organic porosity, relative to the other HP temperature series in all solid bitumen accumulations regardless of size. Overall, the study indicates that temperature and duration of artificial maturation play an important role in the abundance of pores in the HP residues. This work expands on our understanding of the conditions needed for the generation and development of organic porosity in the New Albany Shale and potentially in other marine source-rock petroleum systems.

Citation Information

Publication Year 2021
Title Hydrous pyrolysis of New Albany Shale: A study examining maturation changes and porosity development
DOI 10.1016/j.marpetgeo.2021.105368
Authors Brett J. Valentine, Paul C. Hackley, Javin J. Hatcherian
Publication Type Article
Publication Subtype Journal Article
Series Title Marine and Petroleum Geology
Index ID 70225667
Record Source USGS Publications Warehouse
USGS Organization Eastern Energy Resources Science Center
