Mount St. Helens: Controlled-source audio-frequency magnetotelluric (CSAMT) data and inversions

February 2, 2015

This report describes a series of geoelectrical soundings carried out on and near Mount St. Helens volcano, Washington, in 2010–2011. These soundings used a controlled-source audio-frequency magnetotelluric (CSAMT) approach (Zonge and Hughes, 1991; Simpson and Bahr, 2005). We chose CSAMT for logistical reasons: It can be deployed by helicopter, has an effective depth of penetration of as much as 1 kilometer, and requires less wire than a Schlumberger sounding.

This Data Series provides the edited data for these CSAMT soundings as well as several different types of 1-D inversions (where the signal data are converted to conductivity-versus-depth models). In addition, we include a map showing station locations on and around the volcano and the Pumice Plain to the north.

The apparent conductivity (or its inverse, apparent resistivity) measured by a geoelectrical system is caused by several factors. The most important of these are water-filled rock porosity and the presence of water-filled fractures; however, rock type and minerals (for instance, sulfides and clay content) also contribute to apparent conductivity. In situations with little recharge (for instance, in arid regions), variations in ionic content of water occupying pore space and fractures sampled by the measurement system must also be factored in (Wynn, 2006). Variations in ionic content may also be present in hydrothermal fluids surrounding volcanoes in wet regions. In unusual cases, temperature may also affect apparent conductivity (Keller, 1989; Palacky, 1989). There is relatively little hydrothermal alteration (and thus fewer clay minerals that might add to the apparent conductivity) in the eruptive products of Mount St. Helens (Reid and others, 2010), so conductors observed in the Fischer, Occam, and Marquardt inversion results later in this report are thus believed to map zones with significant water content. Geoelectrical surveys thus have the potential to reveal subsurface regions with significant groundwater content, including perched and regional aquifers. Reid and others (2001) and Reid (2004) have suggested that groundwater involvement may figure in both the scale and the character of some if not all volcanic edifice collapse events. Ongoing research by the U.S. Geological Survey (USGS) and others aims to better understand the contribution of groundwater to both edifice pore pressure and rock alteration as well as its direct influence on eruption processes by violent interaction with magma (Schmincke, 1998).

Citation Information

Publication Year 2015
Title Mount St. Helens: Controlled-source audio-frequency magnetotelluric (CSAMT) data and inversions
DOI 10.3133/ds901
Authors Jeff Wynn, Herbert A. Pierce
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Data Series
Series Number 901
Index ID ds901
Record Source USGS Publications Warehouse
USGS Organization Volcano Science Center
