Oil-source rock correlation studies in the unconventional Upper Cretaceous Tuscaloosa marine shale (TMS) petroleum system, Mississippi and Louisiana, USA

February 11, 2020

The U.S. Geological Survey assessed undiscovered unconventional hydrocarbon resources reservoired in the Upper Cretaceous Tuscaloosa marine shale (TMS) of southern Mississippi and adjacent Louisiana in 2018. As part of the assessment, oil-source rock correlations were examined in the TMS play area where operators produce light (38–45° API), sweet oil from horizontal, hydraulically-fractured wells in an overpressured ‘high-resistivity’ (>5 Ω-m) zone at the base of the TMS. Geochemical data from 39 oil samples and 17 source rock solvent extracts collected from the TMS play area indicate close correspondence for Tuscaloosa Group oils [from lower Tuscaloosa, middle Tuscaloosa (the TMS) and upper Tuscaloosa reservoirs] in thermal maturity (computed from MPI), SARA proportions, n-alkane distributions, isoprenoid and DBT/P ratios, monoaromatic steroids, and δ13C isotopic compositions (from whole oils, saturate and aromatic fractions). Other parameters (normal steranes, extended homohopanes, C31R/C30 hopane, norhopane/hopane and tricyclic terpane ratios, gammacerane/hopane) show most oil samples have similar values, suggesting all Tuscaloosa Group oils are from a common mixed marine-terrigenous source rock. Tighter distributions for triaromatic steroid (TAS) and δ13C isotopic composition for conventional oils in lower and upper Tuscaloosa reservoirs may indicate charge occurred in a single or shorter pulse relative to TMS oils which show broader TAS and δ13C properties, possibly from their generation over an extended period of burial maturation. Dissimilarity in geochemical properties between lower Tuscaloosa source rock solvent extracts and Tuscaloosa Group oils indicates lower Tuscaloosa source rocks did not contribute significantly to conventional and unconventional Tuscaloosa Group hydrocarbon accumulations. Whereas, TMS solvent extracts are similar to Tuscaloosa Group oils, suggesting an oil-source rock correlation. Excluding the possibility for long-distance lateral migration from a similar source downdip (which is unnecessary given thermal maturity considerations), the observations indicate 1. the TMS is a self-sourced reservoir, 2. the TMS is the source of oils accumulated in nearby conventional Tuscaloosa Group reservoirs, and 3. thin organic-rich shales in the lower Tuscaloosa did not contribute substantially to any oil accumulations in the Tuscaloosa Group.

Publication Year 2020
Title Oil-source rock correlation studies in the unconventional Upper Cretaceous Tuscaloosa marine shale (TMS) petroleum system, Mississippi and Louisiana, USA
DOI 10.1016/j.petrol.2020.107015
Authors Paul C. Hackley, Kristin Opferkuch Dennen, Daniel Garza, Celeste Lohr, Brett Valentine, Javin J. Hatcherian, Catherine B. Enomoto, Frank T. Dulong
Publication Type Article
Publication Subtype Journal Article
Series Title Journal of Petroleum Science and Engineering
Index ID 70219032
Record Source USGS Publications Warehouse
USGS Organization Eastern Energy Resources Science Center
