Petrology of the 2004-2006 Mount St. Helens lava dome -- implications for magmatic plumbing and eruption triggering

January 1, 2008

Eighteen years after dome-forming eruptions ended in
1986, and with little warning, Mount St. Helens began to
erupt again in October 2004. During the ensuing two years,
the volcano extruded more than 80×106
of gas-poor,
crystal-rich dacite lava. The 2004-6 dacite is remarkably
uniform in bulk-rock composition and, at 65 percent SiO2
among the richest in silica and most depleted in incompatible
elements of the magmas erupted at Mount St. Helens during the past 500 years. Since shortly after the first spine of
lava appeared, samples have been collected using a steel box
dredge (“Jaws”) suspended 20-35 m below a helicopter and,
occasionally, by hand sampling. As of the spring of 2006, 25
age-controlled samples have been collected from the seven
spines of the new lava dome. Samples were obtained from
both the interiors of spines and from their carapaces, which
are composed of fault gouge and cataclasite 1-2 m thick. The
dacite lava is crystal rich, with 40-50 percent phenocrysts.
The groundmass is extensively crystallized to a cotectic
assemblage of quartz, tridymite, and Na- and K-rich feldspar
microlites, raising the total crystal content to more than 80
percent on a vesicle-free basis in all but the earliest erupted samples. Early samples and those collected from near the
spine margin are more glassy and vesicular that those collected later and from the interior of the spines. Oxide thermobarometer determinations for the earliest erupted samples
we collected cluster at temperatures of approximately 850°C
and at an oxygen fugacity one log unit above the nickel-nickel
oxide (NNO) buffer curve. In contrast, samples from relatively glass-poor samples erupted in late 2004 and early 2005
have zoned oxides with apparent temperatures that range to
greater than 950°C. The higher temperatures in these microlite-rich rocks are attributed to latent heat evolved during
extensive and rapid groundmass crystallization. Low volatile
contents of matrix glasses and presence of tridymite and
quartz in the high-silica rhyolite matrix glass indicate extensive shallow (<1 km) crystallization of the matrix, driven by
degassing of water and solidifying the magma below the level
of the vent. The mode of eruption of the dacite as a series of
fault-gouge-mantled spines is explained by this process of
extensive subvent degassing and solidification.
Although the dacite from this eruption is more silica
rich than 1980-86 dome rocks, most major and trace element
concentrations of the 1980-86 and 2004-6 magma batches are
similar, and magmatic gas emissions have been low and have
had similar ratios to those of the 1980s, raising the possibility
that the magma might be residual from the 1980–86 reservoir.
However, titanium and chromium are enriched slightly relative
to the most recent 1980-86 and Goat Rocks (A.D. 1800-1857)
eruptive cycles, and heavy rare-earth-element abundances are
slightly depleted relative to those erupted during the past 500
years at Mount St. Helens. These data suggest either addition
of new gas-poor dacite magma or tapping of a region of the
preexisting reservoir that was not erupted previously.
A relatively low pressure of last phenocryst growth
suggests that the magma was derived from near the apex of
the Mount St. Helens magma reservoir at a depth of about 5 km. Viewed in the context of seismic, deformation, and
gas-emission data, the petrologic and geochemical data can
be explained by ascent of a geochemically distinct batch
of magma into the apex of the reservoir during the period
1987-97, followed by upward movement of magma into a new
conduit beginning in late September 2004.
The question of new versus residual magma has implications for the long-term eruptive behavior of Mount St. Helens,
because arrival of a new batch of dacitic magma from the deep
crust could herald the beginning of a new long-term cycle of
eruptive activity. It is also important to our understanding of
what triggered the eruption and its future course. Two hypotheses for triggering are considered: (1) top-down fracturing
related to the shallow groundwater system and (2) an increase
in reservoir pressure brought about by recent magmatic replenishment. With respect to the future course of the eruption,
similarities between textures and character of eruption of the
2004-6 dome and the long-duration (greater than 100 years)
pre-1980 summit dome, along with the low eruptive rate of the
current eruption, suggest that the eruption could continue sluggishly or intermittently for years to come.

Publication Year 2008
Title Petrology of the 2004-2006 Mount St. Helens lava dome -- implications for magmatic plumbing and eruption triggering
DOI 10.3133/pp175030
Authors John S. Pallister, Carl R. Thornber, Katharine V. Cashman, Michael A. Clynne, Heather Lowers, Charlie Mandeville, Isabelle K. Brownfield, Gregory P. Meeker
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Professional Paper
Series Number 1750-30
Index ID pp175030
Record Source USGS Publications Warehouse
USGS Organization Volcano Hazards Program
