Practical application of time-lapse camera imagery to develop water-level data for three hydrologic monitoring sites in Wisconsin during water year 2020

Using camera imagery to measure water level (camera-stage) is a well-researched area of study. Previous camera-stage studies have shown promising results when implementing this technology with tight constraints on test conditions. However, there is a need for a more comprehensive evaluation of the extensibility of camera-stage to practical applications. Therefore, the aim of this study was to test a camera-stage method under a wide variety of test conditions to better understand the successes and challenges of using this technology in real-world scenarios. In this study, this approach was tested during Water Year 2020 at three existing U.S. Geological Study (USGS) stream gaging stations in south central Wisconsin that had existing USGS water-level instrumentation. The specific reference objects tested were white pipes and a concrete wall. Since successful application of camera-stage relies on use of suitable images, all captured images in this study were visually inspected to determine suitability for application of camera-stage. Camera-stage measurements were then computed only on images deemed suitable and the results were compared with ground-truth stage values to determine the accuracy. For the purposes of this study, camera-stage values within ±0.10 ft of the actual stage were considered acceptable. One major challenge highlighted was the potential difficulty in obtaining suitable imagery, with the proportion of suitable images varying greatly between the four trials from 38 % to 92 %. The results from applying camera-stage to suitable images were encouraging though, with 79 % to 99 % of evaluated camera-stage values qualifying as acceptable among the four test trials.
