Properties of solid bitumen formed during hydrous, anhydrous, and brine pyrolysis of oil shale: Implications for solid bitumen reflectance in source-rock reservoirs

Solid bitumen reflectance (BR_o in %) is widely used as a thermal maturity proxy in source-rock reservoirs, yet solid bitumen texture and physical attributes may be affected by varying environmental constraints during its formation, e.g., water saturation, mineral catalysis, or salinity. Herein we investigated the development of solid bitumen properties during artificial maturation using three diverse (lacustrine to marine) oil shale samples containing abundant amorphous H-rich sedimentary organic matter (bituminite). The oil shales were treated via pyrolysis (320 °C, 72 h) using hydrous, anhydrous, and brine conditions, causing the development of a newly formed solid bitumen in the experiment residues from the thermal conversion of bituminite. The properties of the newly formed solid bitumen then were evaluated via geochemical screening tests, optical and electron microscopy, and infrared spectroscopy. Experimental residues also were treated via solvent extraction, allowing characterization of the effects of extraction on solid bitumen. Results showed that bituminite with higher resin and asphaltene components evolved to a solid bitumen with higher reflectance (as a percentage of the original value) when exposed to the same heat treatment, relative to bituminite with higher saturate and aromatic components. Aromatization of solid bitumen also was generally more pronounced in the presence of deionized water relative to anhydrous conditions, supporting prior observations. These results suggest the compositions of primary sedimentary organic matter, and the local concentration of water, affect the development of solid bitumen during thermal advance, potentially explaining the origin of multiple solid bitumen populations with varying reflectance in source-rock reservoir samples or in a single microscope field. Experiments using brine were inconclusive regarding enhanced/decreased aromatization, which could be attributed to the salinities of the brines used in the tests. Extraction of residues caused a consistent increase in BR_o values, suggesting that migrating or expelled oils could cause an increase in BR_o via natural solvation and absent an increase in temperature. This work provides insights into the development and evolution of BR_o in source-rock reservoirs as a function of the composition of the original bituminite and changing environmental conditions, with potentially broad application for petroleum prospecting and resource estimation.
