Two-dimensional hydraulic analyses of Joachim Creek, De Soto, Missouri
A two-dimensional hydraulic model; water-surface profiles; and digital maps of water-surface elevation, velocities, and water depths were developed for a 6.7-mile reach of Joachim Creek within and near the city of De Soto, Missouri. Water-surface profiles were generated for the 10-, 4-, 2-, 1-, and 0.2-percent annual exceedance probability (10-, 25-, 50-, 100-, and 500-year recurrence interval) flows. Digital maps of water-surface elevation, water depth, and velocity were generated for the 1- and 0.2-percent annual exceedance probability flows. Water-surface elevations and inundation extents of generated profiles and maps were substantially lower than similar products produced for the 2019 flood-insurance study that included the study reach. The differences in water-surface elevations can be attributed to differences in input streamflows and hydraulic simulation techniques.
The water-surface elevations generated for the 1- and 0.2-percent annual exceedance probability flows were used to assess the vulnerability and inundation depths of 231 selected structures within the city of De Soto. Results indicate that 157 to 177 of the 231 structures were affected at the 1-percent annual exceedance probability flow, depending on the adjacent grade elevation used for reference. Between 185 and 198 structures were affected at the 0.2-percent annual exceedance probability flow, depending on grade elevation. Inundation depths at the affected structures were 0.02 to 9.28 feet (ft), depending on the flow and adjacent grade reference.
Flood elevations were computed for Joachim Creek using a two-dimensional, finite-volume numerical modeling application for river hydraulics. The hydraulic model was calibrated using high-water marks from the April 18, 2013, flood and the maximum measured streamflow at the U.S. Geological Survey streamgage Joachim Creek at De Soto, Mo. (station 07019500), on September 8, 2018. The calibrated model was then used to compute the hydraulic conditions associated with the 10-, 4-, 2-, 1-, and 0.2-percent annual exceedance probability flows. The simulated water-surface elevations and digital elevation model (derived from light detection and ranging data having a 0.60-ft vertical accuracy and a 1.97-ft horizontal resolution) were used to generate products including water-surface profiles and maps of inundated area, water depth, and velocities using model postprocessing software.
Citation Information
| Publication Year | 2021 |
|---|---|
| Title | Two-dimensional hydraulic analyses of Joachim Creek, De Soto, Missouri |
| DOI | 10.3133/sir20215058 |
| Authors | Kyle D. Hix, Paul H. Rydlund, David C. Heimann |
| Publication Type | Report |
| Publication Subtype | USGS Numbered Series |
| Series Title | Scientific Investigations Report |
| Series Number | 2021-5058 |
| Index ID | sir20215058 |
| Record Source | USGS Publications Warehouse |
| USGS Organization | Central Midwest Water Science Center |
