Water-withdrawal and groundwater-level fluctuations, physical and infiltration characteristics of Ohio River sediment, and isotope-based estimates of water sources relative to a riverbank filtration system in an alluvial aquifer, Louisville, Kentucky, 200

The U.S. Geological Survey and the Louisville Water Company, from 2000 to 2020, cooperatively investigated physical and hydrologic conditions in the Ohio River alluvial aquifer and adjacent riverbed sediments in the northeast part of Louisville, Kentucky, to increase knowledge of processes affecting water sources to collector wells during operation of a riverbank filtration system (RBF). The RBF, in 2020, included an initial collector well (CW1) completed in 1999 and a tunnel and collector well system (TCWS) composed of four collector wells (CW2–CW5) completed in late 2010 that were connected by a tunnel that routed water to a pumping station and a treatment plant.

Daily mean water-withdrawal rates typically ranged from about 10.4 to 20.7 million gallons per day (Mgal/d) from 2005 to 2007, then were cyclic from 2008 to 2010 and ranged from as low as about 9 to 13 Mgal/d in winter-spring months up to about 19 to 20 Mgal/d in summer-autumn months. From 2011 through 2017, peak daily mean water-withdrawal rates from CW2–CW5 fluctuated between winter-spring lows of about 20–30 Mgal/d to summer-autumn peak rates of about 41.6 Mgal/d in 2013 to about 48.2 Mgal/d in 2012. From 2017 to 2020, TCWS peak daily mean water-withdrawal rates decreased from about 45.7 Mgal/d in 2017 to about 37.5 Mgal/d in 2020 and peak daily mean rates from CW1 ranged from about 20.7 Mgal/d in 2020 to about 21.6 Mgal/d in 2018. Periods in 2019–20 with tunnel pumping station daily mean water-withdrawal rates smaller than about 30 Mgal/d had generally stable water levels in CW2 and indicated the sustainable yield of the TCWS collector wells under the prevailing hydrologic conditions.

Drawdown during July–August of 2008 and 2009 was associated with CW1, the sole operating collector well. Groundwater-flow directions outside the CW1 cone of depression during July–August of 2008 and 2009 were from areas near the alluvial valley margin toward the Ohio River and in 2009 toward Harrods Creek. Collector wells CW2 through CW5 derived water during 2011–19 surveys from surface-water infiltration, as indicated by drawdown that extended beneath the Ohio River and Harrods Creek. Increases in drawdown toward the alluvial valley margins in July–August of 2013 and 2015, compared with July 2011, indicated less available recharge from those flow directions and decreased yield of groundwater from the aquifer after progressively longer TCWS water withdrawals. Drawdown at CW2–CW5 and at observation wells between them lessened in October 2019 and indicated that onshore groundwater levels can recover when collector well withdrawals decrease.

Overlapping cones of depression in 2011–15 potentiometric surfaces centered around CW2, CW3, CW4, and CW5, and drawdown along divides between those wells indicated well interference between collector wells. Well-interference effects increased during 2013 and 2015 survey periods, despite decreased water-withdrawal rates compared with July 2011, and expanded to include CW1 when its use resumed.

Groundwater-level fluctuations in observation wells near the Ohio River were consistent with gradual depletion of groundwater yield during tunnel pumping station operation at river elevations of about 420 feet above the National Geodetic Vertical Datum of 1929 (NGVD 29) and enhanced recharge of the aquifer when river elevations were above flood stage of about 430 feet above NGVD 29. Groundwater-level declines in observation wells near the Ohio River were most apparent in summer and some autumn months between 2012 and 2017 during periods when tunnel pumping station mean daily water-withdrawal rates were about 35 Mgal/d or more. Periods of relatively stable groundwater levels during 2019–20 in observation wells between CW2–CW5, when tunnel pumping station water-withdrawal rates were about 30–33 Mgal/d or less, also indicated that the prevailing sustainable yield was about 30 Mgal/d or less.

Wells associated with CW3 and CW4 had the largest increases in slopes of best-fit lines relating water-level difference to water-withdrawal rate between 2012 and 2020, an indication of decreased efficiencies of those wells to supply water or of changes in groundwater yield around the well. Increased slopes of best-fit lines relating water-level difference to water-withdrawal rate from 2019 to 2020, when groundwater levels were otherwise relatively stable, also indicated that the specific capacity of one or more TCWS collector wells may have declined during that period.

Riverbed surface elevation, roughness, and hardness changes between hydroacoustic surveys indicated active accretion and erosion of bed sediment offshore from the riverbank filtration system in 2002–4. Riverbed hydraulic conductivity computed from 2013 to 2015 in tests at 11 sites ranged from 0.2 to 230 feet per day. Ten temporary piezometer sites with adjacent operating collector wells had drawdowns that ranged from about 4 to 11.7 feet and hammer blows greater than or equal to 49 counts, which indicated a relatively great density of alluvial sediments and the potential for diminished riverbed infiltration rates.

Contributions of Ohio River infiltration to collector wells estimated from deuterium and oxygen-18 isotopic ratios in representative Ohio River and groundwater samples were considerably larger in warmer months than cooler months and ranged from 80–90 percent in CW1–CW5 in May 2020 to 100 percent in May 2019 at CW2, CW4, and CW5. Groundwater contributions to water withdrawals by collector wells increased in cooler autumn months and ranged from 40 percent at CW3 and CW5 in November 2020 to 70 percent at CW2, CW4, and CW5 in November–December 2019. November 2019 and November 2020 isotopic compositions of water from the collector wells had enriched deuterium and oxygen-18 isotopic ratios consistent with mixtures of evaporation-modified water from the Ohio River and meteoric-origin groundwater.
