Southwest Gravity Program Active
Aquifer monitoring in the Big Chino Valley, Arizona
For this project gravity stations were collocated with monitoring wells to determine the storage/groundwater-level relation
Monitoring Minute 319 storage change
Gravity surveys were used to map infiltrated water during the Minute 319 “Pulse Flow” on the Colorado River
Mapping the Leupp, Arizona alluvial aquifer
Relative-gravity surveys were carried out to map the extent of the alluvial aquifer beneath the Little Colorado River
Tucson aquifer monitoring
The Southwest Gravity Program operates an A-10 absolute gravimeter, a rugged, field-portable instrument
The Southwest Gravity Program provides high-precision time-lapse gravity (repeat microgravity) data for hydrologic studies in the southwestern US. Recent projects include monitoring recharge underneath ephemeral-stream channels, monitoring aquifer-storage change in unconfined and compressible aquifers, measuring storage change at surface-spreading and injection-well artificial-recharge facilities, and estimating specific yield through the correlation of gravity and water-level change in wells. Projects range in scale from the site-specific (individual recharge basins) to regional (for example, the Tucson, Albuquerque, and Phoenix groundwater basins).
Gravity is affected by mass: the greater an object's mass, the stronger its gravitational pull. By measuring changes in gravity over time, inferences can be made about changes in mass. In hydrology, this can be used to study water in the subsurface. If the amount of groundwater in a particular area increases, through processes such as rainfall infiltration and aquifer recharge, gravity will also increase. Likewise, losses of groundwater storage, such as from pumping, discharge to streams, and evaporation, will cause gravity to decrease.
Data are usually collected in project-specific monitoring networks, using absolute gravity meters and relative gravity meters. Changes in gravity, measured as an acceleration (for example, m/s2), are readily converted to a thickness of free-standing water using the “Bouguer,” or infinite-slab, approximation. Data are published as Sciencebase Data Releases and in an online absolute-gravity database. Data releases are primarily network-adjusted (combined) relative- and absolute-gravity data.
The Southwest Gravity Program provides GSadjust software, for the network adjustment of relative- and absolute-gravity data. The software is designed to work with Scintrex and Burris relative-gravity data formats (also, free-format csv data can be entered) and Micro-g Lacoste absolute-gravity formats. GSadjust provides various drift correction options for relative-gravity data and can compute gravity change between surveys. GSadjust is optimized for data interaction, allowing the user to quickly see the effect of choices made during data processing (for example, choice of drift-correction method) on the adjusted gravity values. Also, an Excel Spreadsheet is available that calculates drift correction and gravity differences between stations.
Forecasting Total Dissolved Solids Concentrations of Groundwater from the Lower Colorado Water Supply Project
Aquifer-storage monitoring at Tucson Water’s Heritage Project
Aquifer storage-change monitoring in Albuquerque Basin, New Mexico
Aquifer storage-change monitoring in the Big Chino Subbasin, Yavapai County, Arizona
Monitoring aquifer-storage change at Tucson Water's Southeast Houghton Area Recharge Project
North Phoenix aquifer monitoring with repeat microgravity
Aquifer-Storage Change and Land-Surface Elevation Change Monitoring in the Tucson Active Management Area
Monitoring Network of the Groundwater Flow System and Stream-Aquifer Relations in the Mesilla Basin, Doña Ana County, New Mexico and El Paso County, Texas
Southwest Gravity Program Absolute-Gravity Database (updated 2022-07-08)
MODFLOW-NWT groundwater model demonstrating groundwater model calibration with repeat microgravity measurements
Repeat microgravity data from Santa Cruz River, Tucson, Arizona, 2019-2021
Repeat microgravity data from South Houghton Area Recharge Project, Tucson, Arizona, 2020-2021
Repeat microgravity data from the Hualapai Valley, Mohave County, Arizona, 2008-2019
Repeat microgravity data from Tucson Basin and Avra Valley, Arizona, 2021
Repeat microgravity data from Mesilla Valley, New Mexico, 2016-2018
Repeat microgravity data from Albuquerque and Bernalillo County, New Mexico, 2016-2021 (ver. 3.0, March 2023)
Gravity data from the Truxton area, northwestern Arizona
Repeat microgravity data from the Big Chino Subbasin, 2001-2017, Yavapai County, Arizona
Gravity Change from 2014 to 2015, Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona
Procedures for field data collection, processing, quality assurance and quality control, and archiving of relative- and absolute-gravity surveys
Gravity surveys for estimating possible width of enhanced porosity zones across structures on the Coconino Plateau, Coconino County, north-central Arizona
Improving groundwater model calibration with repeat microgravity measurements
Assessing potential groundwater-level declines from future withdrawals in the Hualapai Valley, northwestern Arizona
Gravity surveys and depth to bedrock in the Truxton basin, northwestern Arizona
Aquifer storage change and storage properties, 2010–2017, in the Big Chino Subbasin, Yavapai County, Arizona
Groundwater-storage change and land-surface elevation change in Tucson Basin and Avra Valley, south-central Arizona--2003-2016
Changes in Earth’s gravity reveal changes in groundwater storage
Time-lapse gravity data for monitoring and modeling artificial recharge through a thick unsaturated zone
Groundwater response to the 2014 pulse flow in the Colorado River Delta
Gravity change from 2014 to 2015, Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona
Hydrological conditions and evaluation of sustainable groundwater use in the Sierra Vista Subwatershed, Upper San Pedro Basin, southeastern Arizona
Accounting for time- and space-varying changes in the gravity field to improve the network adjustment of relative-gravity data
Changes in Gravity used to Quantify Groundwater-Storage Change in the Tucson AMA
The Tucson Active Management Area (AMA) is a semi-arid region in southern Arizona. Historically, groundwater pumping in the Tucson AMA exceeded recharge for many decades. Gravity-based methods developed by the USGS can be used to directly measure groundwater-storage changes, providing an estimate of total storage change that does not rely on uncertain estimates of inflows and outflows.
Gravity Data Spreadsheets
GSadjust: a graphical user interface for processing combined relative- and absolute-gravity surveys
GSadjust is a graphical user interface for processing relative-gravity surveys. It provides an interface for data selection, drift evaluation and correction, network adjustment, for data from modern relative (Scintrex, ZLS) and absolute (Micro-g LaCoste) gravity meters.
- Overview
The Southwest Gravity Program provides high-precision time-lapse gravity (repeat microgravity) data for hydrologic studies in the southwestern US. Recent projects include monitoring recharge underneath ephemeral-stream channels, monitoring aquifer-storage change in unconfined and compressible aquifers, measuring storage change at surface-spreading and injection-well artificial-recharge facilities, and estimating specific yield through the correlation of gravity and water-level change in wells. Projects range in scale from the site-specific (individual recharge basins) to regional (for example, the Tucson, Albuquerque, and Phoenix groundwater basins).
Gravity is affected by mass: the greater an object's mass, the stronger its gravitational pull. By measuring changes in gravity over time, inferences can be made about changes in mass. In hydrology, this can be used to study water in the subsurface. If the amount of groundwater in a particular area increases, through processes such as rainfall infiltration and aquifer recharge, gravity will also increase. Likewise, losses of groundwater storage, such as from pumping, discharge to streams, and evaporation, will cause gravity to decrease.
Data are usually collected in project-specific monitoring networks, using absolute gravity meters and relative gravity meters. Changes in gravity, measured as an acceleration (for example, m/s2), are readily converted to a thickness of free-standing water using the “Bouguer,” or infinite-slab, approximation. Data are published as Sciencebase Data Releases and in an online absolute-gravity database. Data releases are primarily network-adjusted (combined) relative- and absolute-gravity data.
The Southwest Gravity Program provides GSadjust software, for the network adjustment of relative- and absolute-gravity data. The software is designed to work with Scintrex and Burris relative-gravity data formats (also, free-format csv data can be entered) and Micro-g Lacoste absolute-gravity formats. GSadjust provides various drift correction options for relative-gravity data and can compute gravity change between surveys. GSadjust is optimized for data interaction, allowing the user to quickly see the effect of choices made during data processing (for example, choice of drift-correction method) on the adjusted gravity values. Also, an Excel Spreadsheet is available that calculates drift correction and gravity differences between stations.
- Science
Forecasting Total Dissolved Solids Concentrations of Groundwater from the Lower Colorado Water Supply Project
The USGS seeks to increase understanding of the groundwater system in the vicinity of the Lower Colorado Water Supply Project well field and to estimate future groundwater levels and total dissolved solids concentrations in the wells and the long-term viability of the Lower Colorado Water Supply Project.Aquifer-storage monitoring at Tucson Water’s Heritage Project
Tucson Water’s Santa Cruz River Heritage Project releases up to 3,150 acre-feet a year of reclaimed water into the Santa Cruz River channel near downtown Tucson, AZ, much of which is expected to recharge to the subsurface through the channel bottom. Tracking the movement of recharged water is necessary to limit the dispersal of that water within specific target boundaries, and to enable resource...Aquifer storage-change monitoring in Albuquerque Basin, New Mexico
USGS, in cooperation with the Albuquerque Bernalillo County Water Utility Authority, began repeat microgravity measurements in 2015 to monitor aquifer-storage changes in the Albuquerque basin.Aquifer storage-change monitoring in the Big Chino Subbasin, Yavapai County, Arizona
The Big Chino Subbasin is a groundwater basin that includes the Verde River headwaters in Yavapai County in north-central Arizona. Groundwater in the Big Chino Valley discharges to wells (by pumping), by evapotranspiration, and to the upper Verde River springs, which form the headwaters of the Verde River. Groundwater also discharges to short perennial reaches of Williamson Valley Wash, Walnut...Monitoring aquifer-storage change at Tucson Water's Southeast Houghton Area Recharge Project
The Arizona Water Science Center is monitoring aquifer-storage changes at an artificial recharge facility operated by Tucson Water in southeast Tucson. Aquifer-storage change is monitored by measuring changes in gravity over time at the same network of benchmarks. As water is added or removed from the aquifer, there is a change in mass and a corresponding measurable change in gravity.North Phoenix aquifer monitoring with repeat microgravity
The City of Phoenix has traditionally relied on surface-water supplies from the Salt, Verde, and Colorado River watersheds. To increase water-supply resiliency and flexibility, the City is expanding its Artificial Storage and Recovery (ASR) operations in the north Phoenix area. USGS is measuring small changes in gravity caused by groundwater-storage changes to better understand where and when...Aquifer-Storage Change and Land-Surface Elevation Change Monitoring in the Tucson Active Management Area
The Arizona Water Science Center is monitoring aquifer-storage changes and land subsidence within the Tucson Active Management Area (AMA). Land-surface elevation change is monitored at a network of benchmarks throughout the Tucson AMA by measuring changes in land surface elevation over time (approximately annually) with Interferometric Synthetic Aperture Radar (InSAR). Aquifer-storage change is...Monitoring Network of the Groundwater Flow System and Stream-Aquifer Relations in the Mesilla Basin, Doña Ana County, New Mexico and El Paso County, Texas
The Mesilla Basin monitoring program was established in 1987 to document the hydrologic conditions of New Mexico’s southern-most, Rio Grande rift basin. The program’s data collection and reporting is conducted by the U.S. Geological Survey in cooperation with local, state, and federal agencies. Hydrologic data collected as part of the monitoring program provide valuable information to better... - Data
Southwest Gravity Program Absolute-Gravity Database (updated 2022-07-08)
This dataset contains absolute-gravity data collected by the USGS Southwest Gravity Program, a collaborative effort of the Arizona, California, and New Mexico Water Science Centers to monitor and model groundwater-storage change. Data were collected following the methods in "Procedures for Field Data Collection, Processing, Quality Assurance and Quality Control, and Archiving of Relative and AMODFLOW-NWT groundwater model demonstrating groundwater model calibration with repeat microgravity measurements
A numerical model was developed using MODFLOW-NWT and FloPy to simulate groundwater flow and demonstrate a practical method for incorporating repeat microgravity observations (i.e., small changes in the acceleration due to Earth's gravity) as a new type of calibration target for groundwater-flow models. The single-layer, 250-m cell size model was kept relatively simple to focus on the value of repRepeat microgravity data from Santa Cruz River, Tucson, Arizona, 2019-2021
Relative-gravity surveys were carried out using a ZLS Burris relative-gravity meter. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluating gravity change during repeated measurements at one or more base stations. Absolute-gravity surveys were carried out using a Micro-g LaCoste, Inc. A-10 absolute-gravity meter. Vertical gradientsRepeat microgravity data from South Houghton Area Recharge Project, Tucson, Arizona, 2020-2021
Relative-gravity surveys were carried out using a ZLS Burris relative-gravity meter. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluating gravity change during repeated measurements at one or more base stations. Absolute-gravity surveys were carried out using a Micro-g LaCoste, Inc. A-10 absolute-gravity meter. Vertical gradientsRepeat microgravity data from the Hualapai Valley, Mohave County, Arizona, 2008-2019
This dataset contains absolute-gravity measurements made using an A-10 absolute gravity meter (Micro-g Lacoste, Inc.) in 2008, 2009, 2017, 2018, and 2019 in the Hualapai Valley, Mohave County, Arizona. Measurements were made at 9 different stations. Data are presented in tabular form, including relevant parameters used for processing. Data were output by g software (Micro-g Lacoste, Inc.) versionRepeat microgravity data from Tucson Basin and Avra Valley, Arizona, 2021
These data represent the network-adjusted results of relative- and absolute-gravity surveys. Relative-gravity surveys were carried out using two ZLS Corporation Burris relative-gravity meters. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluating gravity change during repeated measurements at one or more base stations. Absolute-graRepeat microgravity data from Mesilla Valley, New Mexico, 2016-2018
This dataset represents the network-adjusted results of relative- and absolute-gravity surveys. Relative-gravity surveys were carried out using a Zero Length Spring, Inc. relative-gravity meter. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluating gravity change during repeated measurements at one or more base stations. Absolute-gRepeat microgravity data from Albuquerque and Bernalillo County, New Mexico, 2016-2021 (ver. 3.0, March 2023)
This dataset represents the network-adjusted results of relative- and absolute-gravity surveys. Relative-gravity surveys were carried out using a Zero Length Spring, Inc. Burris relative-gravity meter. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluating gravity change during repeated measurements at one or more base stations. AbsGravity data from the Truxton area, northwestern Arizona
This dataset represents the network-adjusted results of relative- and absolute-gravity surveys. Data are provided in tabular (csv) and vector (shapefile) formats with one row per station.Relative-gravity surveys were carried out using a ZLS Coporation Burris relative-gravity meter. The effect of solid Earth tides and ocean loading were removed from the data. Instrument drift was removed by evaluatRepeat microgravity data from the Big Chino Subbasin, 2001-2017, Yavapai County, Arizona
This dataset contains absolute-gravity measurements made using an A-10 absolute gravity meter (Micro-g Lacoste, Inc.) between 2009 and 2017 in the Big Chino Subbasin, Yavapai County, Arizona. Measurements were made about 3 times per year at a total of 33 different stations. Data are presented in tabular form, including relevant parameters used for processing. Data were output by g software (Micro-Gravity Change from 2014 to 2015, Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona
Relative-gravity data and absolute-gravity data were collected in the Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona, in May-June 2014 and 2015. Data from 2014 and a description of the survey network were published in USGS Open File Report 2015-1086. Data presented in the shapefile here are: 1) Network-adjusted values from 2015, 2) Gravity change from 2014 to 2015, and 3) Survey-g - Publications
Procedures for field data collection, processing, quality assurance and quality control, and archiving of relative- and absolute-gravity surveys
Repeat microgravity surveys carried out using relative- and absolute-gravity meters are useful for identifying changes in subsurface mass, such as the volume of water stored in an aquifer. These surveys require careful field procedures to achieve the part-per-billion accuracy required to measure the small changes in gravity relevant for hydrologic studies. This chapter describes techniques and metAuthorsJeffrey R. Kennedy, Donald R. Pool, Robert L. CarruthFilter Total Items: 19Gravity surveys for estimating possible width of enhanced porosity zones across structures on the Coconino Plateau, Coconino County, north-central Arizona
The U.S. Geological Survey completed gravity transects in 2015, 2018, and 2019 over four features: the Bright Angel Fault, Bright Angel Monocline, Tusayan Graben, and Redlands Ranch Fault Zone in the Coconino Plateau, Coconino County, Arizona, to determine if the existence and width of high porosity (low density) zones could be inferred from the resulting gravity contrasts, which could be used toAuthorsLibby M. WildermuthImproving groundwater model calibration with repeat microgravity measurements
Groundwater-flow models depend on hydraulic head and flux observations for evaluation and calibration. A different type of observation—change in storage measured using repeat microgravity—can also be used for parameter estimation by simulating the expected change in gravity from a groundwater model and including the observation misfit in the objective function. The method is demonstrated using newAuthorsJeffrey Kennedy, Libby M. Kahler, Jacob E. Knight, Joshua D. LarsonAssessing potential groundwater-level declines from future withdrawals in the Hualapai Valley, northwestern Arizona
A numerical groundwater flow model of the Hualapai Valley Basin in northwestern Arizona was developed to assist water-resource managers in understanding the potential effects of projected groundwater withdrawals on groundwater levels in the basin. The Hualapai Valley Hydrologic Model (HVHM) simulates the hydrologic system for the years 1935 through 2219, including future withdrawal scenarios thatAuthorsJacob E. Knight, Bruce Gungle, Jeffrey R. KennedyGravity surveys and depth to bedrock in the Truxton basin, northwestern Arizona
The volume of available groundwater and the effect of groundwater pumping in an alluvial basin is influenced in part by the shape and depth of the basin boundary, which commonly consists of low-permeability bedrock. To better understand the shape and depth of basin fill in the Truxton valley in Arizona, new gravity data were collected at 149 stations in 2017 and 2018. These data, combined with hisAuthorsJeffrey R. KennedyAquifer storage change and storage properties, 2010–2017, in the Big Chino Subbasin, Yavapai County, Arizona
The Big Chino Subbasin is a groundwater basin that includes the Verde River headwaters in Yavapai County in north-central Arizona. Groundwater in the southern part of the subbasin is found primarily in the Big Chino and Williamson Valleys. The former is a potential municipal water source for growing communities in Yavapai County, particularly groundwater from the Big Chino Water Ranch, about 15 miAuthorsJeffrey R. Kennedy, Libby M. Kahler, Amy L. ReadGroundwater-storage change and land-surface elevation change in Tucson Basin and Avra Valley, south-central Arizona--2003-2016
The U.S. Geological Survey monitors groundwater-storage change and land-surface elevation change caused by groundwater withdrawal in Tucson Basin and Avra Valley—the two most populated alluvial basins within the Tucson Active Management Area. The Tucson Active Management Area is one of five active management areas in Arizona established by the 1980 Groundwater Management Act and governed by the ArAuthorsRobert L. Carruth, Libby M. Kahler, Brian D. ConwayChanges in Earth’s gravity reveal changes in groundwater storage
Changes in the amount of water stored in underground aquifers cause small changes in Earth’s gravitational field. The U.S. Geological Survey’s Southwest Gravity Program has developed methods for measuring terrestrial gravity changes with part-per-billion precision. The measurements allow scientists to map changes in groundwater storage and to improve models that simulate groundwater flow.AuthorsJeffrey R. KennedyTime-lapse gravity data for monitoring and modeling artificial recharge through a thick unsaturated zone
Groundwater-level measurements in monitoring wells or piezometers are the most common, and often the only, hydrologic measurements made at artificial recharge facilities. Measurements of gravity change over time provide an additional source of information about changes in groundwater storage, infiltration, and for model calibration. We demonstrate that for an artificial recharge facility with a deAuthorsJeffrey R. Kennedy, Ty P.A. Ferre, Benjamin CreutzfeldtGroundwater response to the 2014 pulse flow in the Colorado River Delta
During the March-May 2014 Colorado River Delta pulse flow, approximately 102 × 106 m3 (82,000 acre-feet) of water was released into the channel at Morelos Dam, with additional releases further downstream. The majority of pulse flow water infiltrated and recharged the regional aquifer. Using groundwater-level and microgravity data we mapped the spatial and temporal distribution of changes in aquifeAuthorsJeffrey Kennedy, Eliana Rodriguez-Burgueno, Jorge Ramirez-HernandezGravity change from 2014 to 2015, Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona
Relative-gravity data and absolute-gravity data were collected at 68 stations in the Sierra Vista Subwatershed, Upper San Pedro Basin, Arizona, in May–June 2015 for the purpose of estimating aquifer-storage change. Similar data from 2014 and a description of the survey network were published in U.S. Geological Survey Open-File Report 2015–1086. Data collection and network adjustment results are prAuthorsJeffrey R. KennedyHydrological conditions and evaluation of sustainable groundwater use in the Sierra Vista Subwatershed, Upper San Pedro Basin, southeastern Arizona
This study assessed progress toward achieving sustainable groundwater use in the Sierra Vista Subwatershed of the Upper San Pedro Basin, Arizona, through evaluation of 14 indicators of sustainable use. Sustainable use of groundwater in the Sierra Vista Subwatershed requires, at a minimum, a stable rate of groundwater discharge to, and thus base flow in, the San Pedro River. Many of the 14 indicatoAuthorsBruce Gungle, James B. Callegary, Nicholas V. Paretti, Jeffrey R. Kennedy, Christopher J. Eastoe, Dale S. Turner, Jesse E. Dickinson, Lainie R. Levick, Zachary P. SuggAccounting for time- and space-varying changes in the gravity field to improve the network adjustment of relative-gravity data
The relative gravimeter is the primary terrestrial instrument for measuring spatially and temporally varying gravitational fields. The background noise of the instrument—that is, non-linear drift and random tares—typically requires some form of least-squares network adjustment to integrate data collected during a campaign that may take several days to weeks. Here, we present an approach to removeAuthorsJeffrey R. Kennedy, Ty P.A. Ferre - Web Tools
Changes in Gravity used to Quantify Groundwater-Storage Change in the Tucson AMA
The Tucson Active Management Area (AMA) is a semi-arid region in southern Arizona. Historically, groundwater pumping in the Tucson AMA exceeded recharge for many decades. Gravity-based methods developed by the USGS can be used to directly measure groundwater-storage changes, providing an estimate of total storage change that does not rely on uncertain estimates of inflows and outflows.
- Software
Gravity Data Spreadsheets
These gravity data spreadsheets are Microsoft Excel documents containing functions that convert observed meter readings to gravity using the meter calibration table (for LaCoste & Romberg relative-gravity meters), applies a tide correction, calculates and plots drift using the Roman (1946) method, and calculates average gravity differences between each station pair.GSadjust: a graphical user interface for processing combined relative- and absolute-gravity surveys
GSadjust is a graphical user interface for processing relative-gravity surveys. It provides an interface for data selection, drift evaluation and correction, network adjustment, for data from modern relative (Scintrex, ZLS) and absolute (Micro-g LaCoste) gravity meters.
