ARD Landsat Tiles Data Dictionary



Acquisition Date

• Field Definition:  The year, month, and day that the scene was acquired.

          Format:

               YYYY/MM/DD



ARD Version

• Field Definition:  The data version for the Landsat ARD Tile data set.

          Values:

          01



Bounding

• Field Definition:  The latitude and longitude of the boundaries of the tile.

          Values:

          Bounding North Latitude

          Bounding South Latitude

          Bounding East Longitude

          Bounding West Longitude



Latitude Format Decimal Degrees: -90.000 through 90.000

Longitude Format Decimal Degrees: -180.000 through 180.000



CCDC Version

• Field Definition:  The data version for the Landsat CCDC Tile data set.

          Values:

          01



Cloud Cover

• Field Definition:  The percentage of non-fill data in the tile obscured by cloud cover.



Cloud Shadow

• Field Definition:  The percentage of non-fill data in the tile obscured by cloud shadows.



Coordinates - Decimal Degrees

• Field Definition:  The latitude and longitude are provided in decimal degrees for the following fields:

          Values:

          Scene Center Latitude and Longitude

          UL_CORNER_LAT - Corner Latitude

          UL_CORNER_LON - Corner Longitude

          UR_CORNER_LAT - Corner Latitude

          UR_CORNER_LON - Corner Longitude

          LR_CORNER_LAT - Corner Latitude

          LR_CORNER_LON - Corner Longitude

          LL_CORNER_LAT - Corner Latitude

          LL_CORNER_LON - Corner Longitude



          Latitude Format Decimal Degrees: -90.000 through 90.000

          Longitude Format Decimal Degrees: -180.000 through 180.000



          Number of decimal places will vary by dataset – check collection in EE.



Date Entered

• Field Definition:  The date this image was entered into the database at EROS.



Coordinates - Degrees, Minutes, Seconds

• Field Definition:  The latitude and longitude are provided in degrees, minutes, and seconds for the following fields:

          Values:

          Scene Center Latitude and Longitude

          UL_CORNER_LAT - Corner Latitude

          UL_CORNER_LON - Corner Longitude

          UR_CORNER_LAT - Corner Latitude

          UR_CORNER_LON - Corner Longitude

          LR_CORNER_LAT - Corner Latitude

          LR_CORNER_LON - Corner Longitude

          LL_CORNER_LAT - Corner Latitude

          LL_CORNER_LON - Corner Longitude



         Longitude Format:

         DDDMMSS.SSH

         DDD = Degree(s) with a range of 0 through 180

         MM = Minute(s) with a range of 0 through 59

         SS.SS = Second(s) with a range of 0 through 59.99

         H = Hemisphere with E for east and W for west



        Latitude Format:

        DDMMSS.SSH

        DD = Degree(s) with a range of 0 through 90

        MM = Minutes(s) with a range of 0 through 59

        SS.SS = Second(s) with a range of 0 through 59.99

        H = Hemisphere with N for north and S for south



Date Range Begin

• Field Definition:  The first day of data acquisition.



Date Range End

• Field Definition:  The last day of data acquisition.



Date Updated

• Field Definition:  The date this image was updated in the database at EROS. A blank field indicates not yet updated.



Datum

• Field Definition:  The horizontal reference system associated with the image.



Fill

• Field Definition:  The percentage of tile with no data values.



Level-1 Collection

• Field Definition:  Version of Level-1 Collection used in processing.

          Values:

          C01

          C02



Map Projection

• Field Definition:  Geographic projection of the image.

          Values:

          AEA = Albers Equal Area



Satellite

• Field Definition:  Specific Landsat vehicle number used to capture this acquisition.

          Values:

          1 = Landsat satellite #1

          2 = Landsat satellite #2

          3 = Landsat satellite #3

          4 = Landsat satellite #4

          5 = Landsat satellite #5

          7 = Landsat satellite #7

          8 = Landsat satellite #8



Scene Count

• Field Definition:  The number of scenes used in the creation of tile.



Sensor Identifier

• Field Definition:  This field is used to identify the sensor that acquired the original source data.

          Values:

          OLI/TIRS

          ETM+

          TM



Snow Ice

• Field Definition:  The percentage of non-fill data in the tile covered by snow and/or ice.



Spacecraft Identifier

• Field Definition:  Spacecraft from which the data was captured.

           Values:

           Landsat 1

           Landsat 2

           Landsat 3

           Landsat 4

           Landsat 5

           Landsat 7

           Landsat 8



Standing Request Date

• Field Definition:  The date against which future Standing Request queries will run.



Tile Grid Horizontal

• Field Definition:  Horizontal tile number associated with the 5000 x 5000 pixel tile grid within its region.



Tile Grid Region

• Field Definition:  The region associated with the grid coverage area.

          Values:

          CU = CONUS

          AK = Alaska

          HI = Hawaii



Tile Grid Vertical

• Field Definition:  Vertical tile number associated with the 5000 x 5000 pixel tile grid within its region.



Tile Identifier

• Field Definition:  The unique identification of each tile.

  ARD
  LXSS_US_HHHVVV_YYYYMMDD_yyyymmdd_CCC_VVV

  L = Landsat
  X = Sensor (“C” = OLI/TIRS Combined, “E” = ETM+, “T” = TM)
  SS = Satellite (“04” = Landsat 4, “05” = Landsat 5, “07” = Landsat 7, “08” = Landsat 8)
  US = Regional grid of the U.S. (“CU” = CONUS, “AK” = Alaska, “HI” = Hawaii)
  HHH = Horizontal tile number
  VVV = Vertical tile number
  YYYYMMDD = Acquisition year (YYYY) month (MM) day (DD)
  YYYYMMDD = Production year (YYYY) month (MM) day (DD)
  CCC = Level-1 Collection number (“C01,” “C02”)
  VVV = Analysis Ready Data (ARD) Version number (“V01,” “V02”)
  PRODUCT = Data product (“TA” = top of atmosphere reflectance, “BT” = brightness temperature, “SR” = surface reflectance,Product download options append to the Tile Identifier _PRODUCT.tar
  “QA” = quality assessment)

  Example
  LT05_AK_007004_20090817_20170806_C01_V01


  Burned Area
  The BA .tar packages “untar” (unzip) into two individual Georeferenced Tagged Image File Format (GeoTIFF; .tif) raster files with an XML (.xml) metadata file. The two raster files include maximum BP and BC.

  LXSS_US_HHHVVV_YYYYMMDD_yyyymmdd_CCC_VVV_PRODUCT.ext

  L = Landsat
  X = Sensor (“C” = OLI/TIRS, “E” = ETM+, “T” = TM)
  SS = Satellite (“08” = Landsat 8, “07” = Landsat 7, “05” = Landsat 5, “04” = Landsat 4)
  US = Regional grid of the U.S. (“CU” = CONUS)
  HHH = Horizontal tile number
  VVV = Vertical tile number
  YYYY = Acquisition year
  MM = Acquisition month
  DD = Acquisition day
  yyyy = Production year
  mm = Production day
  dd = Production day
  CCC = Level-1 Collection number (“C01”, “C02”, …)
  VVV = Analysis Ready Data (ARD) Version number (“V01”, “V02”)
  PRODUCT = Data product (“BP” = maximum burn probability, “BC” = burn classification)
  ext = File extension (“.tif” = GeoTIFF, “.xml” = Extensible Markup Language)

  Example
  LT05_CU_002006_19920904_20170915_C01_V01_BC.tif


  Dynamic Surface Water Extent
  The DSWE .tar packages “untar” (unzip) into six individual Georeferenced Tagged Image File Format (GeoTIFF) (.tif) raster files and an Extensible Markup Language (XML) (.xml) metadata file. The six raster files include a diagnostic layer, interpreted layer, mask layer, interpreted layer with the mask applied, hillshade, and percent slope.

  LXSS_US_HHHVVV_YYYYMMDD_yyyymmdd_CCC_VVV_PRODUCT.ext

  L = Landsat
  X = Sensor (“C” = OLI / TIRS, “E” = ETM+, “T” = TM)
  SS = Satellite (“08” = Landsat 8, “07” = Landsat 7, “05” = Landsat 5, “04” = Landsat 4)
  US = Regional grid of the U.S. (“CU” = CONUS, “AK” = Alaska, “HI” = Hawaii)
  HHH = Horizontal tile number
  VVV = Vertical tile number
  YYYY = Acquisition year
  MM = Acquisition month
  DD = Acquisition day
  yyyy = Production year
  mm = Production month
  dd = Production day
  CCC = Level 1 Collection number (“C01”, “C02”, etc.)
  VVV = Analysis Ready Data (ARD) Version number (“V01”, “V02”, etc.)
  PRODUCT = Data product (“DIAG” = diagnostic layer, “INTR” = interpreted layer, “INWM” = interpreted layer with mask applied, “MASK” = mask layer, “SHADE” = hillshade, “SLOPE” = percent slope)
  ext = File extension (“.tif” = GeoTIFF, “.xml” = Extensible Markup Language)

  Example
  LC08_CU_006006_20160715_20171205_C01_V01_INTR.tif


  Fractional Snow Covered Area
  The fSCA .tar packages “untar” (unzip) into two individual Georeferenced Tagged Image File Format (GeoTIFF) (.tif) raster files and an .xml metadata file. The two raster files include a per-pixel snow cover fraction and a revised cloud mask.

  LXSS_US_HHHVVV_YYYYMMDD_yyyymmdd_CCC_VVV_PRODUCT.ext

  L = Landsat
  X = Sensor (“C” = OLI / TIRS, “E” = ETM+, “T” = TM)
  SS = Satellite (“08” = Landsat 8, “07” = Landsat 7, “05” = Landsat 5, “04” = Landsat 4)
  US = Regional grid of the U.S. (“CU” = CONUS)
  HHH = Horizontal tile number
  VVV = Vertical tile number
  YYYY = Acquisition year
  MM = Acquisition month
  DD = Acquisition day
  yyyy = Production year
  mm = Production month
  dd = Production day
  CCC = Level-1 Collection number (“C01”, “C02”)
  VVV = Analysis Ready Data (ARD) Version number (“V01”, “V02”)
  PRODUCT = Data product (“SNOW” = fractional snow covered area, “REVCM” = revised cloud mask)
  ext = File extension (“.tif” = GeoTIFF, “.xml” = Extensible Markup Language)

  Example
  LE07_CU_003011_200008285_20170918_C01_V01_REVCM.tif



Tile Production Date

• Field Definition:  The creation date of the Landsat ARD tile product.



Units

• Field Definition:  The mapping units associated with tile.

          Values:

          meters
